First Things First

Step 5: Tune the TV

Tune the TV to the VCR viewing channel. The VCR viewing channel is
channel 3 or 4 or the TV's video input.
• If you connect your VCR using the IN (FROM ANT.) and OUT (TO
TV) jacks with RF coaxial cable, set the 3 CH 4 switch to channel
3 or channel 4 — the channel you want to use on your TV.
• If you connect your VCR using the AUDIO/VIDEO jacks
with audio/video cables, select the TV's video input with
the remote's TV and INPUT buttons to see the signal. See page 59
for more information about your TV's input channel.

Step 6: Turn On the VCR

Press ON • OFF on the VCR's front panel or VCR1 on the remote
control to turn on the VCR. The first time you turn the VCR on, a menu
screen appears. This is the start of a QuickSet Guide which helps you
pick different options for your VCR.

Step 7: Using the QuickSet Guide

The QuickSet Guide is an automated procedure that helps you set up
your VCR. The first time you turn on your VCR, the first screen of the
Guide appears.
Select a language.
Choisissez une langue.
1 English
2 Francais
1. Press 1 for English, or 2 for Français (French).
The remaining menus throughout the set up will appear in the chosen
language. Just follow the step-by-step procedures until the interactive
setup is complete.
If the menu does not appear:
• Make sure the TV is tuned to the same channel as the 3 CH 4
switch or the TV's video input "channel" (see page 59 for more
information).
(Continued on next page)
VCR Viewing Channel
When using the ANTENNA jacks to
connect your VCR, tune your TV to
channel 3 or 4.
When using the audio/video jacks to
connect your VCR, tune your TV to
the TV's video input.
QuickSet Guide
If you choose not to use the QuickSet
Guide to set up the VCR, you can exit
now and return to the Guide through
Setup in the VCR MAIN MENU.
5
