Connections

TV With RF Jack Only

This connection assumes:
• You are connecting antenna, cable, or cable box system.
• Your television has only an RF input jack.
This connection provides:
• Mono sound playback from VCR.
• Record one channel while watching another (except when
using a cable box for all channels).
To use this connection, you must have:
• One coaxial cable for cable or antenna connection; two cables
for a cable box
To connect:
1. Connect cables as shown.
2. Return to First Things First , then follow the steps.
Using This Connection
Tune your TV to channel 3 or 4, whichever one you selected with
the 3CH.4 switch on the back of the VCR.
Auto TV/VCR Setting:
• Set the Auto TV/VCR feature to ON.
To play a tape:
1. Insert a tape.
2. If necessary, press PLAY.
To record one program and watch another:
1. Begin recording a program using one of the recording features.
2. Press the TV•VCR button on the VCR (ANTENNA on remote)
and select a different channel on the TV.
60
CABLE, CABLE BOX, OR ANTENNA
VCR
VIDEO
R-AUDIO-L
OUT
MONO
IN 1
TV
IN FROM
ANT.
VHF/UHF
OUT TO TV
3 CH. 4
CABLE/
ANTENNA
