ADTRAN BLUESOCKET 3045 Quick Start

C A
ONFIGURING THE PPLICATION
More detailed documentation for configuring the BSAP 3040/3045 is provided in the
available online at https://supportforums.adtran.com.
BSAP 3040/3045 LED D
ESCRIPTIONS
BSAP State
Boot Loader Solid Off Solid Green
Initialization Green
Operating Solid Solid Off
System Green Green
Initialization
LAN Solid Flashing Flashing
Initialization Green Green
Orange
(Fast)
Discovering Solid Flashing Flashing
vWLAN Green Green
Green
(Slow)
Firmware Solid Flashing Flashing
Upgrade Green Orange
Green
(Download) (Slow)
Firmware Solid Flashing Flashing
Upgrade (writing Green Orange
Green
or verifying) (Fast)
Firmware Solid Solid Flashing
Upgrade Green Orange
Green
Complete
Operational with Solid Solid Flashing
No Activity on Green Green
Green
Radios
Operational with Solid Solid Flashing
Activity on Green Green
Green
Radios
*
Flash speed varies with data rate. If the data rate is slow, LED flashes slowly. If the date rate is extremely slow, the
LED may appear solid green.
FCC R F I
ADIO REQUENCY NTERFERENCE
This device complies with Part 15 of the Federal Communications Commission (FCC) rules. The operation of this
device is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received including interference that may cause undesired operation.
Additional safety and regulatory guidelines are given in the document
Notice available online at https://supportforums.adtran.com.
T -P S
HIRD ARTY OFTWARE
The software included in the Bluesocket 3040/3045 contains copyrighted software that is licensed under the GNU
General Public License (GPL). For a list of third-party software and their licenses, go to
http://www.adtran.com/software/EULA. You can obtain the complete corresponding source code of such software
components from ADTRAN for a period of three years after our last shipment of this product by sending a money order
or check for $5 to:
ADTRAN, Inc, P.O. Box 933638, Atlanta, GA 31193-3638
Please write GPL Source for product Bluesocket 3040/3045 in the memo line of your payment.
This offer is valid to anyone in receipt of this information.
4
vWLAN Administrator's Guide
2.4GHz 5GHz
1 GE
2.5 GE
Off Solid Solid
Green Green
Off Off Off
Off Off Off
*
Off Off Off
*
Off N/A N/A
*
Off N/A N/A
*
Off N/A N/A
*
Off Solid Solid
*
Green Green
Off Flashing Flashing
*
Green 5G
Green (
2.4G
( LED LED only)
only)
Bluesocket Compliance
Copyright © 2016 ADTRAN, Inc. All Rights Reserved.
B
LUESOCKET
,
P/N 1700965F1, 1700966F1
H
ARDWARE
The following items are included in your shipment:
• Bluesocket 3040 (no external antenna connectors)/3045 (external antenna connectors) Access Point (BSAP)
Off
• Wall/hard ceiling/junction box metal mounting bracket
• Metal mounting bracket hardware: four metal anchors with mounting screws for sheetrock, four plastic anchors
with mounting screws for masonry
Off
• Two T-rail mounting brackets (9/16 and 15/16) for flush and recessed drop ceilings
Off
Off
Off
Off
Off
Off
Off
A
NTENNAS
The Bluesocket 3040 AP includes a total of 10 internal modular high efficiency PIFA omnidirectional antennas - four
internal antennas with 6 dBi peak gain for the 5 GHz radio, four internal antennas with 4 dBi peak gain for the 2.4 GHz
radio, one internal antenna with 3/5 dBi peak gain for the dual band scanning/security radio (2.4/5 GHz respectively) and
one internal antenna with 4 dBi peak gain for the BLE radio.
The Bluesocket 3045 AP includes a total of eight RP-SMA connectors for external antennas and two internal modular
high efficiency PIFA omnidirectional antennas - four RP-SMA connectors for external antennas for the 5 GHz radio, four
RP-SMA connectors for external antennas for the 2.4 GHz radio, one internal antenna with 3/5 dBi peak gain for the dual
band scanning/security radio (2.4/5 GHz respectively) and one internal antenna with 4 dBi peak gain for the BLE radio.
For a list of supported external antennas, refer to the
https://supportforums.adtran.com.
Make a note of the 12-character MAC address and serial number listed on the back of the BSAP
3040/3045 before mounting the BSAP to a wall or other surface. This information will be required
during configuration.
M
OUNTING THE
BSAPs should be positioned for maximum throughput and range between other APs and wireless client devices. Follow
these instructions to mount the BSAP on an interior hard ceiling, wall, or junction box using the appropriate enclosed
mounting kit:
1. BSAP 3045 only: Install the antennas (sold separately) onto the appropriate antenna ports. The antenna ports are
2.4G-1
labeled through
2. Using the metal bracket as template, mark the locations of the four mounting holes on the sheetrock wall, hard
ceiling, or over a junction box.
3. For sheetrock ceiling/walls: Press the point of the metal screw anchors into the sheetrock at the marks. Using a drill
or Phillips-head screwdriver, drive the anchor into the sheetrock until the top is flush with the surface of the wall.
4. For masonry walls: Using a 1/4-inch (6.35 mm) masonry drill bit, drill a hole 1.5-inch (38.1 mm) deep. Tap the
anchor into the hole until the top is flush with the surface of the wall.
Quick Start Guide, 61700965F1-13B, October 2016
