HUSSONG MANUFACTURING CO., INC.
O S S E O 4 5 S L
O S S E O 6 0 S L
Models OSO-45-SL & OSO-60-SL
Electric Fireplace
WARNING
Read and understand the entire installation
and operation manual, including all safety
information, before plugging in or using this
product. Failure to do so may result in fire,
electric shock, or serious personal injury.
This fireplace meets the construction and
safety standards of H.U.D. for application
in
manufactured
according to these instructions.
Hussong Mfg. Co., Inc.
OSO-45-SL & OSO-60-SL
homes
when
installed
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
INSTALLATION AND
OPERATION MANUAL
English and French installation manuals are available through your
local dealer. Visit our website www.kozyheat.com.
Les manuels d'installation en français et en anglais sont disponibles
chez votre détaillant local. Visitez www.kozyheat.com .
Starting Serial Number OSO-45-SL: 22-OS45SL00001-36
Starting Serial Number OSO-60-SL: 22-OS60SL00001-36
Rev. 1, August 2022
Advertisement
Table of Contents
Related Manuals for kozy heat OSSEO 45 SL
Summary of Contents for kozy heat OSSEO 45 SL
- Page 1 INSTALLATION AND OPERATION MANUAL HUSSONG MANUFACTURING CO., INC. O S S E O 4 5 S L O S S E O 6 0 S L Models OSO-45-SL & OSO-60-SL Electric Fireplace WARNING English and French installation manuals are available through your local dealer.
-
Page 3: Homeowner Reference Information
Please retain this owner’s manual for future reference. CON GRAT ULAT I ON S! We welcome you as a new owner of a Kozy Heat electric fireplace. Kozy Heat products are designed with superior components and materials, and assembled by trained craftsmen who take pride in their work. -
Page 5: Table Of Contents
2.5 Front Trim Removal and Installation ............ 13 LIMITED WARRANTY ..............29 2.6 Nailing Flange Installation ............... 14 2.7 Wall Mounted Installation ................ 15 #OSO-45-SL #OSO-60-SL R.1 August 2022 Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces TABLE OF CONTENTS 5... -
Page 7: Important Instructions
A heater has hot and arcing or sparking parts inside. Do not use of other heaters. in areas where gasoline, paint, flammable vapors, or liquids are SAVE THESE INSTRUCTIONS #OSO-45-SL #OSO-60-SL R.1 August 2022 Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces IMPORTANT INSTRUCTIONS 7... -
Page 8: Specifications
The adapter should not be used if a three-slot grounded receptacle is available. Adapter Grounding pin Metal grounding screw Cover of grounded outlet box Figure 1.1, Adapter 8 SPECIFICATIONS Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces #OSO-45-SL #OSO-60-SL R.1 August 2022... -
Page 9: Parts And Hardware
Wood Screw ST Screw Crystals (small) River Rocks Remote Control Nailing Flange Electrical Grommet Cover Plate Wall Bracket (Pre-fixed on the back of the fireplace box) #OSO-45-SL #OSO-60-SL R.1 August 2022 SPECIFICATIONS 9 Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces... -
Page 10: Appliance Dimensions
（530mm） （138mm） （1220mm） 65-1/8'' 21-5/8'' 5-7/8'' 16-1/4'' 60'' 20-7/8'' 5-3/8'' 63'' OSO-60-SL （1654mm） （550mm） （150mm） （412mm） （1524mm） （530mm） （138mm） （1600mm） Figure 1.2, #OSO-45-SL & #OSO-60-SL 10 SPECIFICATIONS Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces #OSO-45-SL #OSO-60-SL R.1 August 2022... -
Page 11: Assembly And Installation
Never exceed the maximum amperage for the circuit. DO NOT plug other appliances into the same circuit. #OSO-45-SL #OSO-60-SL R.1 August 2022 Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces ASSEMBLY AND INSTALLATION 11... -
Page 12: Rough Opening
Dimension ‘J’ includes appliance height plus 1/2” (12mm) clearance Dimension ‘K’ includes appliance depth plus 1/2” (12mm) clearance Figure 2.1, Rough Opening Dimensions 12 ASSEMBLY AND INSTALLATION Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces #OSO-45-SL #OSO-60-SL R.1 August 2022... -
Page 13: Front Trim Removal And Installation
Reverse these steps to install the front trim. Figure 2.3, Front Trim Installation and Removal Figure 2.2, Front Trim Installation and Removal #OSO-45-SL #OSO-60-SL R.1 August 2022 Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces ASSEMBLY AND INSTALLATION 13... -
Page 14: Nailing Flange Installation
(See Section 4.1 Hard Wiring Connection on page 16). Install decorative ember bed media (See Section 5.2 Page 18), and re-install the front trim. Figure 2.4, Nailing Flange Installation 14 ASSEMBLY AND INSTALLATION Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces #OSO-45-SL #OSO-60-SL R.1 August 2022... -
Page 15: Wall Mounted Installation
Figure 2.6, Wall bracket Installation Figure 2.5, Wall bracket Removal Figure 2.7, Wall Installation #OSO-45-SL #OSO-60-SL R.1 August 2022 ASSEMBLY AND INSTALLATION 15 Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces... -
Page 16: Facing And Finishing
This appliance is designed to accommodate finishing material up to 5/8" (16mm) thick. Each square represents 1” (25mm) of mantel projection Top of viewing opening Figure 3.1, Mantel Clearances #OSO-45-SL #OSO-60-SL R.1 August 2022 Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces FACING AND FINISHING 16... -
Page 17: Hard Wiring Installation
Re-install cover plate using (3) screws, as shown in Figure 4.1. Electrical Grommet 7/8" (22.2mm) Diameter Figure 4.1, Cover Plate Removal Figure 4.3, Wiring through Electrical Grommet and Cover Plate 17 HARD WIRING INSTALLATION Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces #OSO-45-SL #OSO-60-SL R.1 August 2022... -
Page 18: Appliance Setup
Hold glass in place and secure with screws previously removed. Reinstall front trim. Figure 5.1, Glass Front Removal and Installation #OSO-45-SL #OSO-60-SL R.1 August 2022 Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces APPLIANCE SETUP 18... -
Page 19: Media Installation
Figure 5.2., Apply an even layer the full width and depth of the ember bed strip. Reinstall glass front and front trim. Figure 5.2, Small River Rock Installation Figure 5.3, Small Crystal Installation 19 APPLIANCE SETUP Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces #OSO-45-SL #OSO-60-SL R.1 August 2022... - Page 20 #OSO-45-SL #OSO-60-SL R.1 August 2022 Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces APPLIANCE SETUP 20...
-
Page 21: Operating Instructions
This is normal and should not occur again unless the appliance is not used for a long period of time. Remote Control Figure 6.1, Operating Components 21 OPERATING INSTRUCTIONS Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces #OSO-45-SL #OSO-60-SL R.1 August 2022... - Page 22 Press once: Indicator lights turns on. Timer defaults to appliance at a selected time. (30) minutes. Settings range from (30) minutes to (8) hours. Press again until desired setting is reached. #OSO-45-SL #OSO-60-SL R.1 August 2022 Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces OPERATING INSTRUCTIONS 22...
- Page 23 Note: To prevent overheating, the heater will blow cool air for 8-10 seconds after the heater turns off. H1 - Low heater on with 750W H2 - High heater on with 1500W 23 OPERATING INSTRUCTIONS Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces #OSO-45-SL #OSO-60-SL R.1 August 2022...
- Page 24 (b5). and brighter. Note: Media bed colors 2, 3, & 4 on pulse (b5) will pul- sate an ember effect. #OSO-45-SL #OSO-60-SL R.1 August 2022 Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces OPERATING INSTRUCTIONS 24...
-
Page 25: Maintenance Instructions
Figure 7.1, Remote Control Battery Replacement 7.2.2 Storage • Store heater and power cord in a clean, dry place when not in use. 25 MAINTENANCE INSTRUCTIONS Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces #OSO-45-SL #OSO-60-SL R.1 August 2022... -
Page 26: Troubleshooting
Replace batteries in remote control. See Section 7.3 Remote work Control Battery Information on page 24. Remote receiver malfunction. Ensure remote receiver is not blocked. Move closer to appliance. #OSO-45-SL #OSO-60-SL R.1 August 2022 Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces TROUBLESHOOTING 26... -
Page 27: Replacement Parts List
Electric Remote Control OSO-ERC Power Cord OSO-PWC Hussong Manufacturing Co., Inc. P.O. Box 577 204 Industrial Park Drive Lakefield, MN 56150-0577, USA OSO-45 & OSO-60 27 REPLACEMENT PARTS LIST Hussong Mfg. Co., Inc. • Kozy Heat Fireplaces #OSO-45-SL #OSO-60-SL R.1 August 2022... -
Page 29: Limited Warranty
Hussong Manufacturing Company, Inc. (Hussong Mfg.) warrants this Warranty coverage beings on the date of original purchase. In the Kozy Heat electric appliance from the date of purchase to the original case of new home construction, warranty coverage begins on the...
