Johnson Controls ZE Series Installation Manual page 4

6021974-UIM-A-1120
Nomenclature
Product Category
Z = Package A/C
Product Identifier
E = Standard Efficiency
C = Cooling Only
Single Stage Natural Gas Heat Options
H = 1 Stage Gas Aluminized Steel
J = 1 Stage Gas Stainless Steel
K = 1 Stage Low Nox Gas Aluminized Steel
L = 1 Stage Low Nox Gas Stainless Steel
1. 3 - 5 ton only
00 = Cooling Only
Gas MBH Input (Unit Size Allowed)
05 = 50 MBH Input (1 Stage 036)
07 = 75 MBH Input (1 Stage 048)
10 = 100 MBH Input (1 Stage 036, 060, 072)
12 = 125 MBH Input (1 Stage 048, 060, 072)
4
3-6 Ton Model Number Nomenclature
Z E 036 C
Nominal Cooling Capacity
036 = 3 Ton
048 = 4 Ton
060 = 5 Ton
072 = 6 Ton
Heat Type
1
1
Heat Capacity
Blower Option
A = Direct Drive
B = Standard Static
D = High Static
2. 3 - 5 ton only
Outdoor Air Option
A = No Economizer
C = Economizer w/o Barometric RLF
F = Econ BAS Rdy w/o Barometric RLF
00 A 2 A 1 A
2
Voltage
1 = 208/230-1-60 3
2 = 208/230-3-60
4 = 460-3-60
5 = 575-3-60
3. 3 - 5 ton only
1 = No Service Options
2 = DSC (Disconnect Switch)
3 = NCO (Non-PWR Conv. Outlet)
4 = PCO (Powered Conv. Outlet)
5 = DSC,NCO
6 = DSC,PCO
A A 1 A 1
Product Generation
1 = First Generation
2 = Second Generation
Cabinet Options
A = Std Cabinet
B = HDF(HingedFLTR/Tooless DR)
E = SSD (SST Drain Pan)
F = SSD, HFD
Additional Options
1 = Std Throwaway Filter
2 = 2" Pleated Filters (Merv 8)
4 = Coil Guard (CG), STD Filter
5 = 2" Pleated Filter,CG
Refrigeration
A = Standard Refrigeration
B = ECC (E-Coat Cond Coil)
C = EEC (E-Coat Evap Coil)
F = ECC,EEC
Controls Option
A = Stand Alone Smart Equipment™
4
B = Simplicity Lite
C = BACnet MSTP,Mdbs,N2 COM Card
M = Verasys Single Zone
N = Verasys Change Over Bypass
4. 3 - 5 ton only
Sensors
A = No Sensors
B = PHM (Phase Monitor)
C = DFS (Dirty Filter Switch)
D = SSD (Supply Air Smoke DET)
E = RSD (Return Air Smoke DET)
F = PHM,DFS
G = PHM,SSD
H = PHM,RSD
J = DFS,SSD
K = DFS,RSD
L = SSD,RSD
M = PHM,DFS,SSD
N = PHM,DFS,RSD
P = PHM,SSD,RSD
Q = DFS,SSD,RSD
R = PHM,DFS,SSD,RSD
Service Options
Johnson Controls Ducted Systems
