Ze036-072 Unit Clearances; Ze036-072 Fixed Outdoor Air Motorized Damper Rain Hood Physical Dimensions; Ze036-072 Disconnect Location - Johnson Controls ZE Series Installation Manual

6021974-UIM-A-1120
Figure 7: ZE036-072 Fixed Outdoor Air Motorized Damper Rain Hood Physical Dimensions
Table 4: ZE036-072 Unit Clearances
Location
Front
Rear
Left Side (Filter Access)
Right Side (Cond. Coil)
1
Below Unit
2
Above Unit
1. Units may be installed on combustible floors made from
wood or class A, B, or C roof covering material.
2. Units must be installed outdoors. Overhanging structures
or shrubs should not obstruct condenser air discharge
outlet.
10
27-1/2
Rear View
Clearance
24" (Cooling)
32" (Gas Heat)
12" (Less Economizer)
36" (With Economizer or Fixed
Air)
24" (Less Economizer)
36" (With Economizer)
24"
0"
72" (For
Condenser Air Discharge)
27-1/2 1-5/8
27-1/2
7-1/4
27-1/2
19-1/8
Dimension "A"
Fixed
Outdoor
12
Air Damper
Motorized
16-1/2
Damper
Filter Access
Blower Motor Access
Dot Plugs
Field-Supplied Disconnect
Switch Location
Figure 8: ZE036-072 Disconnect Location
19-1/2 44-7/8
Detail "A"
"A" 44-7/8
LH End View
Detail "B"
Mounting Bracket for
Disconnect Switch
A,B
(Field Supplied)
Wiring Entry
(See Detail "B")
Disconne t Switch Location
and Motor Access Panel for
Unit with "Belt-Drive" Option
Johnson Controls Ducted Systems
19-3/4
10-1/4
3-1/2
8-1/4
4-3/8
Control Box Access
