Table 9: ZE036-072 Physical Data

ZE036-072 Physical Data

Component
Nominal Tonnage
ARI COOLING PERFORMANCE
Gross Capacity @ AHRI A point (Btu)
AHRI net capacity (Btu)
EER
SEER
IEER
IEER IntelliSpeed
CFM
System power (KW)
Refrigerant type
Refrigerant charge (lb-oz)
System 1
AHRI HEATING PERFORMANCE
Heating model
Heat input (K Btu)
Heat output (K Btu)
AFUE% (Single Phase Only)
FER Compliant Direct Drive (Single Phase
3
Gas Heat Only)
FER Compliant Belt Drive (Single Phase
3
Gas Heat Only)
Steady state efficiency (%) (3 Phase Only)
No. burners
No. stages
Temperature Rise Range (ºF)
Gas Limit Setting (ºF) - Direct Drive
Gas Limit Setting (ºF) - Belt Drive
Gas piping connection (in.)
DIMENSIONS (inches)
Length
Width
Height
OPERATING WT. (lbs.)
COMPRESSORS
Type
Quantity
Unit Capacity Steps (%)
CONDENSER COIL DATA
Face area (Sq. Ft.)
Rows
Fins per inch
Tube diameter (in.)
Circuitry Type
EVAPORATOR COIL DATA
Face area (Sq. Ft.)
Rows
30
ZE036
3
36600
35500
12.0
14.0
-
-
1200
2.96
R-410A
4-4
H05 H10 H07
50 100 75
40 80 60
81 81 81
Yes Yes Yes
Yes Yes Yes
80 80 80
2 4 3
1 1 1
15-45 45-75 25-70
240 190 210
240 210 240
1/2 1/2 1/2
82 1/4
44 7/8
32 5/8
470
Scroll
1
100
16.3
1
23
0.71 / 18
2-pass Microchannel 2-pass Microchannel
5.06
3
Models
ZE048 ZE060
4
49100 59000
47500 57000
12.0 11.8
14.0 14.0
-
-
1450 1680
3.96 4.83
R-410A R-410A
5-6 6-4
H12 H10
125 100
100 80
81 81
Yes Yes
Yes No
80 80
5 4
1 1
45-75 25-55
165 170
210 210
1/2 1/2
82 1/4 82 1/4
44 7/8 44 7/8
32 5/8 32 5/8
598 632
Scroll Scroll
1
100 100
16.3 16.3
1
23 23
0.71 / 18 1.00 / 25.4
2-pass Microchannel
5.06 5.06
4
ZE072
5 6
68000
66000
1
11.20 /11.00
-
- -
- 14.2
2057
5.9
R-410A
6-6
H12 H10
125 100
100 80
81 -
Yes -
Yes -
80 80.0
5 4
1 1
35-75 25-55
165 -
210 210
1/2 1/2
82 1/4
44 7/8
32 5/8
665
2-stage scroll
1 1
67/100
16.3
1 1
23
1.00 / 25.4
2-pass Microchannel
5.01
4 4
Johnson Controls Ducted Systems
2
H12
125
100
-
-
-
80.0
5
1
30-75
-
210
1/2
