Johnson Controls ZE Series Installation Manual page 20

6021974-UIM-A-1120
ZE036-072 - Without Powered Convenience Outlet (Belt Drive High Static) (Continued)
Compressors
Size (each)
Volt
(Tons)
RLA LRA MCC
208-3-60 16 110
230-3-60 16 110
060
(5.0)
460-3-60 7.8 52
575-3-60 5.7 38.9
208-3-60 19.6 136
230-3-60 19.6 136
072
(6)
460-3-60 9.4 66.1
575-3-60 7.1 55.3
1. Minimum Circuit Ampacity.
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
4. Single phase, high static belt drive motors not available on gas heating units.
20
OD Fan Supply Pwr
Motors Blower Conv
(each) Motor Outlet
FLA FLA FLA
24.9 4.4 6.8 0
24.9 4.4 6.8 0
12.1 4.4 3.15 0
8.9 4.4 2.2 0
27 4.4 8.3
27 4.4 8.3
13 2.4 4.1
10 4.4 3.2
Electric Heat Accessory
Model kW Stages Amps
NONE - -
E05 4 1 11.1
E07 5.6 1 15.5
E10 8 1 22.2
E15 11.9 2 33
E20 15.9 2 44.1
E30 22.2 2 61.6
NONE - -
E05 5.3 1 12.7
E07 7.5 1 18
E10 10.6 1 25.5
E15 15.9 2 38.2
E20 21.2 2 51
E30 29.6 2 71.2
NONE - -
E07 6.8 1 8.2
E10 10.1 1 12.1
E15 13.6 2 16.4
E20 19.5 2 23.5
E30 28.8 2 34.6
NONE - -
E10 10.6 1 10.2
E15 15.9 2 15.3
E20 21.2 2 20.4
E30 30.4 2 29.3
None - -
E05 4 1 11.1
E07 5.6 1 15.5
E10 8 1 22.2
E15 11.9 1 33
E20 15.9 2 44.1
E30 22.2 2 61.6
None - -
E05 5.3 1 12.7
E07 7.5 1 18
E10 10.6 1 25.5
E15 15.9 1 38.2
E20 21.2 2 51
E30 29.6 2 71.2
None - -
E07 6.8 1 8.2
E10 10.1 1 12.1
E15 13.6 1 16.4
E20 19.5 2 23.5
E30 28.8 2 34.6
None - -
E10 10.6 1 10.2
E15 15.9 1 15.3
E20 21.2 2 20.4
E30 30.4 2 29.3
Max
2
Fuse /
1
MCA
3
Breaker
(Amps)
Size
(Amps)
- 31.2 40
31.2 40
31.2 40
36.3 45
49.8 50
63.7 70
85.5 90
- 31.2 40
31.2 40
31.2 40
40.4 45
56.3 60
72.2 80
97.5 100
- 15.1 20
15.1 20
19.1 20
24.4 25
33.3 35
47.2 50
- 11.1 15
15.5 20
21.9 25
28.2 30
39.3 40
- 37.2 50
37.2 50
37.2 50
38.1 50
51.6 60
65.5 70
87.4 90
- 37.2 50
37.2 50
37.2 50
42.3 50
58.1 60
74.1 80
99.4 100
- 18.3 25
18.3 25
20.3 25
25.6 30
34.5 35
48.4 50
- 13.9 20
16.8 20
23.1 25
29.5 30
40.6 45
