Johnson Controls ZE Series Installation Manual page 31

ZE036-072 Physical Data (Continued)
Component
Nominal Tonnage
Fins per inch
Tube diameter
Circuitry Type
Refrigerant control
CONDENSER FAN DATA
Quantity of fans
Fan diameter (Inch)
Type
Drive type
Quantity of motors
Motor HP each
No. speeds
RPM
CFM
BELT DRIVE EVAP FAN DATA
Quantity
Fan Size (Inch)
Type
Motor Sheave
Blower Sheave
Belt
Motor HP each
RPM
Frame size
DIRECT DRIVE EVAP FAN DATA
Quantity
Fan Size (Inch)
Type
Motor HP each
RPM
FILTERS
15" x 20" x 1" or 2"
14" x 25" x 1" or 2"
1. Cooling Only Unit
2. Cooling Unit with Gas Heat
3. FER or Fan Energy Rating is a Department of Energy (DOE) requirement for single phase gas/electric product rated 65K or less of cooling
capacity. DOE ruling effective 7/2019.
4. ECM O.D. Fan Motor
5. Only Available On 208/230 Volt Models
Johnson Controls Ducted Systems
ZE036
3
13
0.375
Intertwined
Orifice
1
24
Prop
Direct
1
1/2
1
1090
4000
1
11 x 10
Centrifugal
1VL44 1VP56
AK64 AK66
A37 A39
1-1/2 1-1/2
1740
56
5
1
11 x 10
Centrifugal
3/4
1050
2
1
Models
ZE048
4
13
0.375
Intertwined
Orifice
1
24
Prop
Direct
1
1/2
1
1090
4000
1
11 x 10
Centrifugal
1VL44 1VP56 1VL44
AK56 AK61 AK56
A36 A38 A36
1-1/2 1-1/2 1-1/2
1740
56
1
11 x 10
Centrifugal
1
1050
2
1
6021974-UIM-A-1120
ZE060 ZE072
5
13
0.375 0.375
Intertwined Intertwined
TXV TXV
1
24
Prop Prop
Direct Direct
1
3
1/2
1
1100 900 / 1150
4200 3300 / 4200
1
11 x 10 11 x 10
Centrifugal Centrifugal
1VP56 VL44
AK56 AK56
A38 A36
2 1-1/2
1740 1740
56
1
11 x 10
Centrifugal
1
1050
2
1
6
13
1
24
1
4
1/2
2
1
1VP56
AK56
A38
3
56
-
-
-
-
-
2
1
31
