INSTALLATION INSTRUCTIONS
PACKAGED HEAT PUMP
FEATURING R-410A
13.4 SEER2 J4PH4 SERIES - (2-5Tons)
Thank you very much for purchasing our product,
Before using your unit , please read this manual carefully and keep it for future reference.
The figure shown in this manual is for reference only and may be slightly different from the actual product.

Advertisement

Table of Contents
loading

Related Manuals for Trane 13.4 SEER2 J4PH4 Series

Summary of Contents for Trane 13.4 SEER2 J4PH4 Series

  • Page 1 INSTALLATION INSTRUCTIONS PACKAGED HEAT PUMP FEATURING R-410A 13.4 SEER2 J4PH4 SERIES - (2-5Tons) Thank you very much for purchasing our product, Before using your unit , please read this manual carefully and keep it for future reference. The figure shown in this manual is for reference only and may be slightly different from the actual product.

  • Page 2: Table Of Contents

    RECOGNIZE THIS SYMBOL AS AN INDICATION OF IMPORTANT SAFETY INFORMATION WARNING These instructions are intended as an aid to qualified, licensed service personnel for proper installation, adjustment and operation of this unit. Read these instructions thoroughly before attempting installation or operation. Failure to follow these instructions may result in improper installation, adjustment, service or maintenance possibly resulting in fire, electrical shock, property damage, personal injury or death.

  • Page 3: Safety

    This document is customer property and is to remain WARNING with this unit. Disconnect all power to the unit before starting These instructions do not cover all the different maintenance. Failure to do so can result in variations of systems nor does it provide for every possible contingency to be met in connection with severe electrical shock or death.

  • Page 4: Inspection

    CAUTION 2.3 Rigging and Handing Exercise care when moving the unit. Do not remove any A manufactured (mobile) home installation must packaging until the unit is near the place of installation. conform with the Manufactured Home Rig the unit by attaching chain or cable slings to the Construction and Safety Standard, Title 24 lifting holes provided in the base rails.
  • Page 5 Condenser fan motor Highly efficient enhanced copper tube/Aluminum fin outdoor coil Highly efficient enhanced aluminum / aluminum fin indoor coil Decorative protective coil guard Electric heater assembly (optional) Compressor Heavy gauge removable base rails Blower motor with slide-out blower assembly Fig.
  • Page 6 Unit size:024, 030, 036 Front Hi./Lo. pressure service port 1/4’’ SAE Condensate drain connection 3/4” NPTI Low voltage entrance 7/8” Dia. (Trap required) High voltage conn. 1-3/8” Dia. Electrical service access compartment panel Fig. 2-2 Unit Dimensions * The above figure for reference purpose only.
  • Page 7 Unit size:024, 030, 036 Bottom View 50-1/4″ 1-3/4″ Back View 1-5/8″ 14-1/2″ 4-3/8″ 14-1/2″ Side return Side supply air opening air opening Fig. 2-3 Dimensions Back and Bottom * The above figure for reference purpose only.
  • Page 8 Unit size:042, 048, 060 Front Hi./Lo. pressure service port 1/4’’ SAE Condensate drain connection 3/4” NPTI Low voltage entrance 7/8” Dia. (Trap required) High voltage conn. 1-3/8” Dia. Electrical service access compartment panel Fig. 2-4 Unit Dimensions * The above figure for reference purpose only.
  • Page 9 Unit size:042, 048, 060 Bottom View 56-3/4″ 1-3/4″ Back View 2-1/4″ 14-1/2″ 6-5/16″ 14-1/2″ Side return Side supply air opening air opening Fig. 2-5 Dimensions Back and Bottom * The above figure for reference purpose only.

  • Page 10: Ductwork

    A closed return duct system shall be used. This shall not Table 2-1: Unit Clearance preclude use of economizers or ventilation air intake. Flexible joints may be used in the supply and return duct Direction Distance (in.) Direction Distance (in.) work to minimize the transmission of noise.

  • Page 11: Electrical Wiring

    6 ELECTRICAL WIRING • Power wiring is connected to the power terminal block in unit electric cabinet. See Electrical Heater Installation Instruction for details. Field wiring must comply with the National Electric Code (NEC) or Canadian Electrical Code (CEC) and any applicable local ordinance.
  • Page 12 CAUTION Label all wire prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. CONTACTOR Field-supplied disconnect Single GROUND phase PLUG power supply Refer to electrical data tables to size the disconnect Fig.
  • Page 13 Table 6-2: 13.4 SEER2 Physical Data Models Models Models Models Models Models Component Nominal Tonnage ARI COOLING PERFORMANCE 95°F Capacity rating (Btu/h) 22800 28200 34200 40500 46000 57000 SEER2 13.4 13.4 13.4 13.4 13.4 13.4 Nominal CFM 1060 1200 1450 1450 1700 System power (kW)

  • Page 14: Airflow Performance

    7 AIRFLOW PERFORMANCE Airflow performance data is based on cooling performance with a coil and no filter in place. Use this performance table for appropriate unit size, external static applied to unit and allow operation within the minimum and maximum limits shown in table below for both cooling and electric heat operation.
  • Page 15 Table 7-2 Duct Application(230V) SCFM Motor Model External Static Pressure-Inches W.C.[kPa] Speed Number 0[0] 0.1[.02] 0.2[.05] 0.3[.07] 0.4[.10] 0.5[.12] 0.6[.15] 0.7[.17] 0.8[.20] SCFM Watts Low-Tap(1) Amps 2.07 2.07 2.06 2.05 SCFM Mid-Tap(2) Watts (Factory) Amps 2.31 2.28 2.26 2.24 SCFM Watts High-Tap(3) Amps...
  • Page 16 ● Air supply diffusers must be selected and located carefully. They must be sized and positoined to deliver treated air along the perimerter of the space. If they are too small for their intended airflow, they become noisy. If they are not located properly, they cause drafts.
  • Page 17 Table 7-5 Refrigerant charge for H/P system Heating Charge Chart/Tableau De Charge de Chauffage Heating Mode Indoor Dry Bulb Temperature(oF)/Temperature Interieur au Themometre sec(en oF) Mode De Chauffage High Pressure Service Port(psig)/Vanne Détecté de Pression Haute(en psig) Table 7-6 Refrigerant charge for H/P system Cooling Charge Chart/Tableau De Charge de Refroidissement Cooling Mode Outdoor Ambient Temperature(oF)/Temperature Amdiante Exterieure(en oF)
  • Page 18 Table 7-7 Refrigerant charge for H/P system Heating Charge Chart/Tableau De Charge de Chauffage Heating Mode Indoor Dry Bulb Temperature(oF)/Temperature Interieur au Themometre sec(en oF) Mode De Chauffage High Pressure Service Port(psig)/Vanne Détecté de Pression Haute(en psig) Table 7-8 Refrigerant charge for H/P system Cooling Charge Chart/Tableau De Charge de Refroidissement Cooling Mode Outdoor Ambient Temperature(oF)/Temperature Amdiante Exterieure(en oF)
  • Page 19 Table 7-9 Refrigerant charge for H/P system Heating Charge Chart/Tableau De Charge de Chauffage Heating Mode Indoor Dry Bulb Temperature(oF)/Temperature Interieur au Themometre sec(en oF) Mode De Chauffage High Pressure Service Port(psig)/Vanne Détecté de Pression Haute(en psig) Table 7-10 Refrigerant charge for H/P system Cooling Charge Chart/Tableau De Charge de Refroidissement Cooling Mode Outdoor Ambient Temperature(oF)/Temperature Amdiante Exterieure(en oF)
  • Page 20 Table 7-11 Refrigerant charge for H/P system Heating Charge Chart/Tableau De Charge de Chauffage Heating Mode Indoor Dry Bulb Temperature(oF)/Temperature Interieur au Themometre sec(en oF) Mode De Chauffage High Pressure Service Port(psig)/Vanne Détecté de Pression Haute(en psig) Table 7-12 Refrigerant charge for H/P system Cooling Charge Chart/Tableau De Charge de Refroidissement Cooling Mode Outdoor Ambient Temperature(oF)/Temperature Amdiante Exterieure(en oF)
  • Page 21 Table 7-13 Refrigerant charge for H/P system Heating Charge Chart/Tableau De Charge de Chauffage Heating Mode Indoor Dry Bulb Temperature(oF)/Temperature Interieur au Themometre sec(en oF) Mode De Chauffage High Pressure Service Port(psig)/Vanne Détecté de Pression Haute(en psig) Table 7-14 Refrigerant charge for H/P system Cooling Charge Chart/Tableau De Charge de Refroidissement Cooling Mode Outdoor Ambient Temperature(oF)/Temperature Amdiante Exterieure(en oF)

  • Page 22: System Operation

    Table 7-15 Refrigerant charge for H/P system Heating Charge Chart/Tableau De Charge de Chauffage Heating Mode Indoor Dry Bulb Temperature(oF)/Temperature Interieur au Themometre sec(en oF) Mode De Chauffage High Pressure Service Port(psig)/Vanne Détecté de Pression Haute(en psig) 8 SYSTEM OPERATION High pressure protection If high pressure is ＞609PSIG,the compressor and the outdoor fan motor will stop running.

  • Page 23: Thermostat Signals

    8.4 Thermostat Signals Start-up conditions of defrost mode When SW3-1 switch is set to “ON”(See Fig 8-1), the system will perform a defrost cycle in any of the following Table 8-1: Thermostat Signals conditions: 1. If the compressor is operating and T3 is < 32 °F, the Signal Board Function State...

  • Page 24: Operation Check-Up

    9 OPERATION CHECK-UP 10 TROUBLE SHOOTING • Cooling Startup WARNING 1. Turn thermostat to OFF and turn power to ON Component trouble shooting requires opening 2. Turn ON thermostat and set as high as possible control box with power on. 3.

  • Page 25: Troubleshooting Table

    10.3 Troubleshooting Table SYSTEM FAULTS REFRIGERANT CIRCUIT Head Pressure Too High Head Pressure Too Low Suction Pressure Too High Suction Pressure Too Low Liquid Refrig. Floodback (TXV) I.D. Coil Frosting Compressor Runs Inadequate or No Cooling/Heating ELECTRICAL Compressor & O.D. Fan Won’t Start Compressor Will Not Start But O.D.
  • Page 29 此页不做菲林，仅核对使用 印刷技术要求 材质 封面封底内页双胶纸80g 规格 A4规格 颜色 黑白 其他 设计更改记录表 （仅做说明用，不做菲林） 涉及更改页面 版本升级 更改人 更改日期 更改主要内容 （印刷页码） 电辅热型号勘误， 表6-2勘误，表7-2 10页、11页、12页 徐乐乐 20221213 电机转速档位描述 更改...
