Pro-Form HYBRID TRAINER PRO User Manual page 13

15. Identify the Right and Left Seat Handlebars
(29, 93).
Slide the Right Seat Handlebar (29) onto the
right side of the Seat Frame (61).
Attach the Right Seat Handlebar (29) with two
M8 x 38mm Bolts (95) and two M8 Locknuts
(68); make sure that the Locknuts are in the
hexagonal holes (I).
Repeat this step to attach the Left Seat
Handlebar (93).
16. Attach the Seat Frame (61) to the Seat Carriage
(32) with four M6 x 35mm Screws (98); start all
the Screws, and then tighten them.
15
93
61
95
16
32
13
I
68
29
98
98
61
