Connection
IMPORTANT
Use solid or stranded wires (twisted or with ferrule).
Wire cross-section/gauge for all wire connectors:
• 1 core: 0.5 to 2.5 mm
• 2 cores: 0.5 to 1.5mm
• 3 cores: not permitted.
NOTE
To know more about each port's specifications, see
USER MANUAL Version 1.0.0
2
(24 to 11 AWG).
2
(24 to 15 AWG).
M-BUS to BACnet/IP Server Gateway
Technical Specifications (page 12).
