8

Software

To make settings, first install the software for the measuring device. Then connect the meter to
the computer.
Symbol
8.1

Carry out settings of the data logger

To make settings now, go to Settings. Under the tab "Datalogger", you can make settings for the
measuring device.
Setting
Current Time
Start Mode
Sample Rate
Max Point
Record Time
Enable high and low alarm
Temperature / Humidity
High Alarm
Low Alarm
Other
LED flash cycle
Temperature Unit
LoggerName:
Humidity Unit:
Description
Open measurement sequences saved via the software
Save measurement sequences recorded via the software
Read out sensors live
Download data stored in the meter
Settings for the measuring device and the software
Open software instructions
Change view between live data transmission and downloaded
measurement data
Description
The current time of the computer which is used for data
recording is displayed here.
Here you can set when the meter is to start recording data.
When "Manual" is selected, you can start recording by pressing
a key. When "Instant" is selected, recording starts immediately
after the settings have been overwritten.
Here you can set the saving interval.
The maximum possible data records that the measuring device
can save are displayed here.
This shows you for how long the meter can record data until the
memory is full.
Activate the limit value alarm function by ticking the box.
Set the alarm limits for temperature and humidity.
"Temperature" stands for the temperature measurement
"Humidity" stands for relative humidity
With "High Alarm", you set the desired upper limit value.
With "Low Alarm", you set the desired lower limit value.
Via this function, you set the intervals at which the LED should
light up to indicate operation.
Here you set the temperature unit.
Here you can give the data logger a name.
The current ambient humidity unit is displayed here. This unit
cannot be changed.
