- Page 1 ASSEMBLY INSTRUCTIONS WARNING! Serious or fatal injuries can occur from furniture tip over. Use tip over restraint (steel band included) to secure this product to the wall. Description : BROOKLYN 3 DRAWER NIGHTSTAND Item No. : BD-8003 ITEM NO.: BD-8003 Printed in Vietnam REVISED MAR 27, 2019 - 1 -...
-
Page 2: Before Assembly
BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning assembly, however, make sure all parts and hardware are included and free of obvious defect. -
Page 3: Part List
PART LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts: Description Sketch Description Sketch Side panel (L-R) Bottom frame Back panel Back rail Drawer front Drawer side Drawer back (L-R) -
Page 4: Hardware List
HARDWARE LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the following hardware: Description Sketch Description Sketch Allen key Bolt (M4 x 30mm x 110mm) (M6 x 30mm) Spring washer Flat washer (6.5 x 11mm) - Page 5 STEP 1 ttach top (A), back rail (E) and bottom frame (C) to side panel (B) with bolts (2), and washers (3) and (4) as shown below. Tighten with Allen key (1). Slide back panels (D) into the grooves as shown below STEP 2 Attach bottom frame (C) and top (A) to the other side panel (B) with bolts (2), and washers (3) and (4) as shown below.
- Page 6 STEP 3 Attach back rail (E) to side panels (B) with screws (5) as shown below .Tighten with a screwdriver. STEP 4 Attach drawer sides (G) to drawer front (F) with screws (5) as shown below. Tighten with a screwdriver. Insert drawer bottom (I) into the grooves at bottom of drawer sides (G) and drawer font (F) as shown below.
- Page 7 STEP 5 Attach support bars (J) to bottom of drawers with screws (8) as shown below. Tighten with a screwdriver. Attach knobs (7) to front of drawers with pan head screws (6) as shown below. Tighten with a screwdriver. Carefully put the drawers into the unit. STEP 6 Attach steel bands (9) to the unit with screws (10) as shown below.
