SFP specifications
Table 3: IEEE 802.3z 1000BASE-SX (MT-RJ) SFP specifications
Connectors
Cabling
Distance
Wavelength
Link optical power budget
Transmitter characteristics
Launch power
Receiver characteristics
Receiver sensitivity
Maximum input power

1000BASE-LX SFP specifications

The 1000BASE-LX SFP provides 1000BASE-LX gigabit Ethernet connectivity at 1310
nanometers (nm) using single mode or multimode optical fiber. The 1000BASE-LX SFP
supports full-duplex operation only. The part number for this model is AA1419015-E5.
The following table describes standards, connectors, cabling, and distance for the 1000BASE-
LX SFP.
Table 4: IEEE 802.3z 1000BASE-LX SFP specifications
Connectors
Cabling
Distance
Wavelength
32 Installation — SFPs
Parameter
Parameter
Specifications
Duplex MT-RJ
• 62.5 µm MMF optic cable
• 50 µm MMF optic cable
• up to 275 m using 62.5 µm MMF optic cable
• up to 550 m using 50 µm MMF optic cable
850 nm
7.0 dB
– 10 to – 4.0 dBm
– 17 dBm
0 dBm
Specifications
Duplex LC
• 50 micrometer (µm) multimode fiber (MMF)
• 62.5 µm multimode fiber
• 9 µm single mode fiber (SMF)
• Up to 550 meters (m) using MMF
• Up to 10 kilometers (km) using SMF
1310 nm
