MIXER
AR 100 MK 1
Installation and Operation Manual
S/N: 32000
Rev.: 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AR 100 MK 1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Metos AR 100 MK 1

Summary of Contents for Metos AR 100 MK 1

  • Page 1 MIXER AR 100 MK 1 Installation and Operation Manual S/N: 32000 Rev.: 2.0...
  • Page 3 Dear Customer, Congratulations on deciding to choose a Metos appliance for your kitchen activities. You made an excellent choice. We will do our best to make you a satisfied Metos customer like thousands of customers we have around the world.
  • Page 4 14.2.2005 Rev. 2.0...

  • Page 5: Table Of Contents

    14.2.2005 Rev. 1. General ......................1 1.1 Symbols used in the manual ..................1 1.2 Symbols used on the appliance ..................1 1.3 Checking the relationship of the appliance and the manual .......... 2 2. Safety ......................3 2.1 Safety instructions in case of malfunction ..............3 2.2 Disposal of the appliance ....................
  • Page 6 14.2.2005 Rev. 7. Troubleshooting ..................17 9. Technical specifications ................61...

  • Page 7: General

    14.2.2005 Rev. 2.0 General 1. General Carefully read the instructions in this manual as they contain important information re- garding proper, efficient and safe installation, use and maintenance of the appliance. Keep this manual in a safe place for eventual use by other operators of the appliance. The installation of this appliance must be carried out in accordance with the manufactur- er’s instructions and following local regulations.

  • Page 8: Checking The Relationship Of The Appliance And The Manual

    14.2.2005 Rev. 2.0 General 1.3 Checking the relationship of the appliance and the manual The rating plate of the appliance indicates the serial number of the appliance. If the man- uals are missing, it is possible to order new ones from the manufacturer or the local rep- resentative.

  • Page 9: Safety

    14.2.2005 Rev. 2.0 Safety 2. Safety Putting your fingers in the bowl-or into attachment drive if any-while the mixer is running may cause injuries. 2.1 Safety instructions in case of malfunction Please take careful note of the following instructions and warnings: 2.2 Disposal of the appliance Once the appliance has reached the end of its useful life, it must be disposed of in com- pliance with local rules and regulations.

  • Page 10: Functional Description

    14.2.2005 Rev. 2.0 Functional description 3. Functional description 3.1 General This appliance does not contain parts which can be serviced by the user. Maintenance must be carried out by authorised personnel. 3.2 Intended use of the appliance The appliance is intended for manufacture of products which do not during processing cause reactions or emit substances which may be detrimental to the user 3.3 Construction of the mixer...

  • Page 11: Operation Instructions

    14.2.2005 Rev. 2.0 Operation instructions 4. Operation instructions 4.1 Operation of the mixer A Open the safety guard and place the bowl in the bowl arms. The bowl arms must be in the lowest position and the bowl must be pushed all the way into the bowl arms (fig.2 or fig.3).
  • Page 12 14.2.2005 Rev. 2.0 Operation instructions C Raise the bowl to working position by clockwise turn of the button for bowl lift (fig.1), ensure that the bowl is placed correctly. Close the safety guard D If the mixer is equipped with a timer, set the mixing time requred by turning the timer (fig.1) clockwise.

  • Page 13: Recommended Maximum Speeds

    14.2.2005 Rev. 2.0 Operation instructions G Before the mixer is stopped, the speed selector lever must be moved back to the lowest speed (fig.4). H Stop the mixer by pressing the red stop button 0 (fig.1). 4.1.1 Recommended maximum speeds Please take note of the recommended maximum speeds below:...

  • Page 14: Procedure For Starting After Emergency Stop

    14.2.2005 Rev. 2.0 Operation instructions 4.1.2 Procedure for starting after emergency stop This procedure must be used in cases where the mixer has been stopped in high speed. • Lower the bowl and remove the tool from the bayonet. • Raise the bowl arms,either empty or with the bowl.

  • Page 15: Correct Use Of Tools

    14.2.2005 Rev. 2.0 Operation instructions 4.1.5 Correct use of tools The meat mincer must not be used for production of bread crumbs as this will cause un- necessary wear and tear on some mixer parts. Whips should not be struck against hard objects as e.g. the edge of the bowl. This will make the life of the tool shorter due to increasing deformity.

  • Page 16: Maintenance And Lubrication

    14.2.2005 Rev. 2.0 Operation instructions Please note that the plastic safety guard can be damaged if exposed to high temperature for a considerable period (Max. temperature 65°C). After using the attachment drive, it should be wiped inside with a soft cloth. 4.2.2 Maintenance and lubrication The infinitely variable gear must be lubricated regularly, i.e.
  • Page 17 14.2.2005 Rev. 2.0 Operation instructions Lubrication of other movable parts: The movable parts of the bowl arms, the shaft and the lifting rod must also be lubricated with oil. Remove the rear covering and lubricate the marked points with an oil can (fig.5 point 2).

  • Page 18: Installation

    14.2.2005 Rev. 2.0 Installation 5. Installation 5.1 Preparing the installation It should be checked that all loose parts are delivered with the mixer such as bowl, tools, grease gun and rubber feet. 5.2 Installation Never lift the mixer by the handle for speed adjustments or for bowl lift. The mixer is placed directly on the floor.

  • Page 19: Adjustment Instructions

    14.2.2005 Rev. 2.0 Adjustment instructions 6. Adjustment instructions Prior to a possible repair or adjustment, switch off the mixer by disconnecting the power cable. 6.1 Adjustment of special V-belt The distance (X) is only indicative as it depends on the tolerance of the special V-belt. Start by tightening the V-belts (*) Tighten the special V-belt (A) by moving one or two washers from (V) to (T).

  • Page 20: Adjustment Of Speed

    14.2.2005 Rev. 2.0 Adjustment instructions On the front pulley set the stud (E) on the varispeed collar (F) must be placed inside the lower fork (G) and on the rear pulley set outside the fork for belt tightener (B), (both must point backwards).

  • Page 21: Adjustment Of Bowl Fixing

    14.2.2005 Rev. 2.0 Adjustment instructions 6.3.1 Adjustment of bowl fixing The bowl arms must be raised to normal working position. The adjusting diameter (Y) shall be measured inside between the bowl arms (fig.6a): Adjusting diameter (Y): AR 100 = 554 mm In case the bowl fastening is too loose, remove the lock ring (B) and draw the bearing (A) from the shaft (C).
  • Page 22 14.2.2005 Rev. 2.0 Adjustment instructions The upper and lower position of the bowl is determined by microswitch (1) and (2), (fig.7b). The two mechanical stops consisting of the bolts (3) and (4) are adjusted so that they will be hit approx. 1mm after the microswitch, in case the microswitch should fail. the upper position of the bowl arms is adjusted by bending the spring arm of the micro switch (2) either forwards or backwards;...
  • Page 23 14.2.2005 Rev. 2.0 Troubleshooting 7. Troubleshooting If the appliance fails to work, check to ensure that • it has been used according to instructions • all removable parts are in place • the disconnection switch (usually on a wall or in the immediate vicinity of the ap- pliance) is in the ON position •...
  • Page 24 14.2.2005 Rev. 2.0 Troubleshooting...
  • Page 25 14.2.2005 Rev. 2.0 Technical specifications 9. Technical specifications Wiring diagram: electrical connection: 3ph.+0+gr. Ctrl.volt. to relay:1ph.+0 Wiring diagram: electrical connection:3ph.+gr.Ctrl. volt.to relay:2 phases Wiring d-m:electrical connec- tion:1ph.+0+gr.or2ph.+gr.Ctrl.volt.to relay:1ph.+0 or Installation drawing AR 101-22.24...
  • Page 26 Wiring diagram: electrical connection: 3ph.+0+gr. Ctrl.volt. to relay:1ph.+0...
  • Page 27 Wiring diagram: electrical connection:3ph.+gr.Ctrl. volt.to relay:2 phases...
  • Page 28 Wiring d-m:electrical connection:1ph.+0+gr.or2ph.+gr.Ctrl.volt.to relay:1ph.+0 or 2ph...
  • Page 29 14.2.2005 Rev. 2.0 Technical specifications Safety switch for bowl lift Safety switch for safety guard Safety switch for lid Timer Emergency stop Microswitch for upper position of the bowl Microswitch for lower position of the bowl...
  • Page 30 Installation drawing AR 101-22.24...
  • Page 31 14.2.2005 Rev. 2.0 Technical specifications Item Model Specification Capacity 100L Motor 100=AR 100 MK 1...
