- Page 1 Mixer with removable safety guard Metos SP-100-A/NH, SP-100 A, SP-200-A/NH, SP-200 A 4025012, 4025016, 4025022, 4025025 Instruction manual...
-
Page 2: Table Of Contents
Model #:__________________ Serial #:__________________ SPAR FOOD MACHINERY MFG, CO., LTD. Instruction Manual for HI‐Series Mixer (SP‐100A, SP‐100A/nh, SP‐200A, SP‐200A/nh, SP‐22HA, SP‐22A, SP‐30HA, SP‐30A, SP‐34HA, SP‐34A, SP‐40HA, SP‐40A, SP‐50HA, SP‐50A, SP‐60HA, SP‐60A) SPAR FOOD MACHINERY MFG. CO., LTD. NO. 145, 11 Industry Rd. Ta Li City, Taichung Hsien, Taiwan, 412 R.O.C. Tel：(886)4‐2491‐7585 Fax：(886)4‐2491‐7565 http://www.sparmixers.com e‐mail：spar@tcts.seed.net.tw CONTENTS Overall View of the Mixer ……………………………………….…………….… P. 2 Installation Instructions ……………………………………..………………… P. 3 Operating Instructions ……………………………………….….…………… P. 4 Cleaning Instructions …………………………………….……………….… P. 10 Maintenance ………………………………...……….………….… P. 10 Limited Warranty …………………………………………..…..…….… P. 11 ... - Page 3 CAUTION Read before you operate the machine It is important to read this manual and following the instructions before operate the machines. This mixer is designed as a safe and efficient food processing product as long as the machine is used in accordance with the instructions in this manual and is properly maintained. User has taken following precautions in order to operate the mixer safely. All operators should be at least 18 years old and are adequately trained and supervised. Also, have fully read and understood this manual. Owner should not let customer, visitor or other unauthorized people come in contact with this machine. Do not wear loose clothes or ring while operating, and keep hands, hair and clothing away the moving parts. NEVER use an extension cord to connect electrical power. Make sure the safety guard is closed and bowl is lifted to right position before operating. NEVER reach into the bowl when the mixer is running. NEVER place your hand or any kitchen utensil in the bowl whilst the mixer is in operation. When mixing product always follow the recommends agitator and speed setting according to the capacity chart. STOP the mixer before changing speed. STOP the mixer before removing or installing attachments into the hub. NEVER put your hand and finger into the feed chute when using any mixer’s attachments, include VH‐12 Meat Mincer and V99S Vegetable Slicer. Always use the pusher plate with attachment. ...
-
Page 4: Overall View Of The Mixer
Overall View of the Mixer Model SP‐60HA A) Bowl B) Removable Bowl Guard C) Planetary Shaft D) Attachment Hub* E) Control Panel F) Gear Lever G) Additions Chute H) Bowl Lift Handle (Wheel) I) Bowl Cradle NOTE: Attachment Hub is optional. ... -
Page 5: Installation Instructions
Installation Instructions INSTALLATION ‐ The machine is supplied factory lubricated and ready to run. It should be positioned on any solid, level and non‐skid work surface that is nonflammable. Install in work area with adequate light and space. ‐ For SP‐ 22HA or Smaller Capacity Model, you may place the mixer on bench which is capable of supporting a load of mixer’s weight. For safety, the mixer should be BOLTED in position using all four holes located in the legs, bolt size L50 mm 3/8". ‐ DO NOT attempt to lift the mixer alone. ‐ Clean the mixer before use. It is normal for the factory to apply a generous amount of grease in and on the machine before initial use. ‐ During the transportation or fitting, please do not lean over 35 degree to avoid the gear oil leaking from the gear oil container. ‐ Please use forklift to transporting. Please refer to Figure 1. Figure 1 ELECTRICAL CONNECTION CAUTION: NEVER USE EXTENSION CORD. Low amp supply could damage the mixer or cause a fire. CAUTION: The user should install an over‐current protection device (e.g. fuse or NFB) or Residual Current Device (GFCI) in the machine incoming site power lines to prevent a fault current risk. CAUTION: The machine is designed for TN power system. ... -
Page 6: Operating Instructions
Installation Instructions ‐ The minimum requirement for all electrical equipment is correct operation between air temperature of +5℃ and +40℃. ‐ Electrical equipment is capable of operating correctly when the relative humidity does not exceeding 95% at a maximum temperature of +40℃. ‐ Electrical equipment is capable of operating correctly at altitude up to 1000m. ‐ Electrical equipment is designed to withstand to protected against the effects of transportation, and storage temperature within a range of ‐25℃ to +55℃ and for short periods not exceeding 24h at up to +70℃. Operating Instructions BEFORE USING THE MIXER Before using the mixer, ensure that all users are familiar with the correct operation of the machine. In particular, care should be taken to ensure that the bowl and mixing tools are correctly fitted and that the bowl guard is in position prior to starting the machine. SAFETY AT WORK ‐ NEVER place your hand or any kitchen utensil in the bowl whilst the mixer is in operation. ‐ Keep hands, hair and clothing away from moving parts. ‐ Isolate the machine from the electrical supply by removing the plug from the socket before cleaning, servicing or adjusting any parts or attachments. ‐ Do not use the machine with any cover or guard removed. Certain operator notice advising about the safe use of this mixer is attached to ... - Page 7 Operating Instructions ‐ TOOL SELECTION Beater: Firm mixes such as light The beater, whisk and spiral dough hook are tools for pastry, cakes biscuits, icings the work implied by their names. Do not use the beater fillings and mashed vegetables. for dough making or the whisk for anything other than whisking, aerating or mixing light mixtures. Spiral Dough Hook: Heavy mixes The Table 1 shows the typical uses for each of the such as dough, pie pastry. . tools. For more details, please refer to Page 14. NOTE: Always wash agitator with mild soap and apply Whisk: Light mixes such as light quantity of mineral oil to planetary shaft after whipped cream, mayonnaise, cleaning. egg whites, pancakes and soufflés. Table 1 FITTING THE BOWL With the bowl cradle lowered, place the chosen mixing tool in the bowl and position the bowl on the cradle. There are three location points when fitting the bowl. Please refer to Figure 2: (1) The locking pin at the rear of the bowl should locate in the hole of the cradle. (2) The two holes in the bowl handles must engage on the pins located on the cradle. ...
- Page 8 Operating Instructions THE REMOVABLE BOWL GUARD The interlocking bowl guard now is available to remove for cleaning purpose. With separated handles, it can easy take out the bowl guard and cleaning in a sink or dishwasher. Open / Closing the Bowl Guard: To open the bowl guard, holding the separated handle, and rotating clockwise. (See Figure A) Figure A To close the bowl guard, rotating counterclockwise until the bowl guard is in the locked position. (See Figure B) NOTE: When the guard is open or not properly installed, the mixer will not operate. NOTE: Removable Bowl Guard is not available for SP‐A80HI, SP‐A80I, SP‐B80HI and SP‐B80I. Figure B Removing and Attaching the Bowl Guard: NOTE: Before removing or attaching the bowl guard, make sure the bowl is in the down/lower position and the agitator is taking off from the planetary ...
- Page 9 Operating Instructions CONTROLS The Timer (C) is arranged to automatically stop the machine after the selected interval. An untimed position is provided for manually controlled mixing cycles. Before starting the mixer it is necessary to set the mixing duration or select the manual position – the mixer will not operate in the 0 position. TIMED OPERATION For timed operation turn the Timer Knob (C) to the desired time (duration is marked from 1 to 15 in graduations of one minute) and then press the Green Start Button (B) to start the mixer. After the timed period you set, the mixer will stop automatically. If it is necessary to stop the mixer before the end of the timed period, press the Red Stop Button (A). UNTIMED OPERATION If you wish to manually control a mix, select the untimed mode by moving the Timer Knob anti‐clockwise to the green mark until it stops. NOTE: Timer is optional on Model SP‐100A, SP‐100A/nh, SP‐200A and SP‐200A/nh. POWER BOWL LIFT NOTE: Power Bowl Lift is only available for Model SP‐A80HI and SP‐A80I. Powered by an electric motor, the bowl may be raised or lowered by fingertip control through the conveniently located switch. Please press (D) Bowl Raise Button to raise the Bowl Cradle. You can lower the Bowl Cradle by pressing (E) Bowl Lower Button. CAPACITY Please refer to Page 12. The table shows the recommended capacities of finished weights of regular mixes. Although the machine may be capable of mixing larger quantities, it will lead to excessive and premature wear and possible failure. Overloading also results in lengthy processes and unsatisfactory results. ℃ NOTE: Reduce batch size by 10%, if chilled flour, water below 20 ...
-
Page 10: Bowl Scraper
Operating Instructions SPEED SELECTION Before changing speeds, the mixer must always be STOPPED first. The necessary speed can then be selected before restarting the machine by pressing the Green Start Button. NOTE: The Model SP‐A80HI, SP‐A80I, SP‐B80HI and SP‐B80I will automatically shut off if the speed is changed during operation. The speed selected depends largely on the quantity and consistency of the product. It is recommended that mixing is always started at the lowest speed and progressively increased to the desired setting. In an emergency situation always use the Red Emergency Stop Button to stop the machine. Table 2 shows the recommended speeds for the range of tools. For Model SP‐A80HI, SP‐A80I, SP‐B80HI and SP‐B80I, please refer to Table 3. Recommended Speed Recommended speed Speed Speed Speed 4 Speed Speed Speed Speed Whisk Whisk Beater Beater ... - Page 11 Operating Instructions IDEAL RECIPES FOR USE WITH THE BOWL SCRAPER Scratch Mashed Potatoes Instant Mashed Potatoes Pancake and Waffle Batters Cake Batters Sugar Cookies Icings Mayonnaise Biscuit Batter Cheesecakes Creaming Shortenings Creaming Eggs/Sugar ATTACHMENTS NOTE: Attachment Hub is optional. The ranges of attachments that can be operated from the Attachment Hub are listed below. When using an attachment, lubricate the Drive Stud (D) using a food quality grease or oil. To fix to the mixer refer to Figure 4. Release the Thumbscrew (G) and slide the shaft of the attachment into the hub ensuring that the Drive Stud (D) engages in the socket within the hub. Rotate the attachment to line up the Location Peg (E) with its mating hole in the hub and push firmly home. Tighten thumbscrew to secure. Figure 4 CAUTION: Only fit attachments when the mixer is stationary and never when it is operating. Do not use attachments when mixing. The recommended speed range for some of the attachments available is shown in table below. Recommended speed gear gear 3 gear V99S Veg. Prep. VH‐12 Mincer ...
-
Page 12: Cleaning Instructions
Cleaning Instructions CARE OF YOUR MIXER CAUTION: ALWAYS DISCONNECT OR UNPLUG THE ELECTRICAL POWER FROM THE MIXER BEFORE CLEANING. The mixer is designed for simple maintenance carried out by operators. It may be necessary from time to time to apply a little Vaseline and oil to the rods on which the bowl cradle slides. If so, use a little food quality lubricant, ensuring that there is no excess oil that could contaminate the food mix. Clean the mixer thoroughly after use. After isolating the machine from the electricity supply, the body should be wiped down with a damp cloth. Do not spray the machine with or immerse it in water. Do not forget to clean the rear of the machine and do not allow the rear vents to become blocked as this may result in overheating. Pay particular attention to the bowl pins and any surrounding areas of the cradle to prevent the accumulation of mix, as this could prevent correct location of the bowl. For the same reason ensure that the beater shaft and each of the sockets on the tools are cleaned thoroughly. The bowl and tools should be washed in hot soapy water, rinsed and dried before being put into storage. Do not wash the agitator s in a dishwasher, as the polished finish will be adversely affected by the dishwashing chemicals. Maintenance ‐ It is recommended that any servicing or maintenance work must be carried out by a trained technician or electrician. CAUTION: ‐ ALWAYS DISCONNECT OR UNPLUG THE ELECTRICAL POWER FROM THE MIXER BEFORE DOING MAINTENANCE. MAINTENANCE Regular maintenance is necessary on all machines if they are to remain in good working condition. It is strongly recommended that all maintenance must be carried out by trained technicians from an appointed distributor. ON A REGULAR BASIS Clean the machine thoroughly after use and lubricate the rods with Vaseline or lubrication oil which the bowl cradle slides. After cleaning the beater shaft, please wipe and lightly lubricate the beater shaft with Vaseline to prevent rusting. (SEE CARE ON YOUR MIXER) ON AN ANNUAL BASIS* ... -
Page 13: Limited Warranty
Maintenance GEAR OIL METER NOTE: Oil Meter Indicator is only available for SP‐A80HI, SP‐A80I, SP‐B80HI and SP‐B80I. Use the gear oil to lubricate the mixer and to prolong the life of the mixer. Before using the mixer, please check the gear oil meter. When the indicator of gear oil meter is above the half of the red circle, the gear oil is full. Please re fill the gear oil when the indicator is below the red circle. GEAR OIL RENEWAL CAUTION: Please use Mobil lubricant “UBE HD 85W‐140” to refill the gearbox of model SP‐A80HI, SP‐A80I, SP‐B80HI and SP‐B80I. Please unscrew and leak the oil from the indicated oil‐leaking hole. After finishing the leaking, re‐screw back tightly with the anti‐leaking coat on the screw. Fill the gear oil to the indicated re‐fill oil hole. We recommended that this servicing or maintenance work must be carried out by trained technicians from a SPAR appointed distributor. GEARBOX LUBRICANT In terms of the rest model from SP‐100A to SP‐60HA, please refill the lubricant inside the gearbox every 5 years. We recommended that this servicing or maintenance work must be carried out by trained technicians from a SPAR appointed distributor. CAUTION: Please use either Mobil lubricant “XHP 222” or Brugarolas “GRASA AGUILA PLEX 2‐BOLSA” to refill the gearbox of model SP‐100A, SP‐100A/nh, SP‐200A, SP‐200A/nh, SP‐22HA, SP‐22A, SP‐30HA, SP‐30A, SP‐34HA, SP‐34A, SP‐40HA, SP‐40A, SP‐50HA, SP‐50A, SP‐60HA and SP‐60A. PLANETARY UNIT LUBRICANT Please add only 2 pumps of grease to the planetary grease fitting once a year. In case there is a strange noise coming from the planetary unit, please reapply grease to the planetary unit by using the grease gun. We recommended that this servicing or maintenance work must be carried out by trained technicians from a SPAR appointed distributor. CAUTION: Please use TACBECON grease “GL‐210” to lubricate the planetary unit. ... -
Page 14: Troubleshooting
Troubleshooting FAULT FINDING FAULT CHECK POSSIBLE REASON AND ACTION REQUIRED No power to mixer Check plug socket Mixer not plugged into a live socket or not switched on Check wiring in plug Plug incorrectly wired – rewire correctly Check fuse in plug Possible faulty fuse – replace fuse Check or change cable Cable damaged or split – replace cable Check microswitch Limit switch damaged or faulty – replace switch Check circuit breaker Circuit breaker shut off or constantly short – reset over load or short or replace the circuit breaker (automatically reset). Mixer falls to operate 1. Check bowl guard/lift Machine will not operate with guards open Check timer position Mixer will operate on timer or manual position Check transmission belt only. Check gear change lever Belt damaged or broken‐replace belt Machine will not operate if out of gear‐put in gear Mixer becomes noisy Check bowl and tools Ensure that bowl and tool are correctly seated. Check work surface Uneven surfaces create excessive resonance. Check bearing for wear Worn bearings – replace bearings Check gearbox ... -
Page 15: Capacity Chart Table
Capacity Chart Table Agitator SP‐100A SP‐200A SP‐22HA SP‐30HA SP‐40HA SP‐50HA SP‐60HA SP‐A80HI, SP‐A80I, Product and and and and and and and and SP‐B80HI, SP‐B80I Speed SP‐100A/nh SP‐200A/nh SP‐22A SP‐30A SP‐40A SP‐50A SP‐60A Waffle or Hot Cake Beater 5 qts. 8 qts. 10 qts. 12 qts. 16 qts. 20 qts. 24 qts. ... -
Page 16: Mixer Agitator/Application
MIXER AGITATOR/APPLICATION ATTACHMENT APPLICATION FOOD PRODUCTS RECOMMENDATIONS Multi purpose agitator Mashing potatoes Use 1 FLAT BEATER speed for starting Mixing cakes Medium speed for finishing Icings Maximum blending of air Whipping cream 2 WIRE WHIP & 3 speeds for 3 speed Beating egg whites into light products mixers 3 & 4 speeds for 4 speed mixers ...
