Chapter 1
Name
(Wireless 2.4GHz)
(Wireless 5GHz)
(LAN)
Slow blinking
Quick blinking
(WPS)
Note:
After a device is successfully added to the network by WPS function, the WPS LED will keep on for about 5 minutes
and then turn off.
1. 3. 2.

The Back Panel

The AP device's back panel shows the connection ports, buttons and antennas. Refer to
the following for detailed instructions (view from left to right).
LED Explanation
Status
The wireless 2.4GHz band is working properly (in AP/Multi-SSID
mode).
On
The host AP's 2.4GHz network is selected (in Repeater/Bridge/Client
mode).
The wireless 2.4GHz band is disabled (in AP/Multi-SSID mode).
Off
The host AP's 2.4GHz is not selected (in Repeater/Bridge/Client
mode).
The wireless 5GHz band is working properly (in AP/Multi-SSID mode).
On
The host AP's 5GHz network is selected (in Repeater/Bridge/Client
mode).
The wireless 5GHz band is disabled (in AP/Multi-SSID mode).
Off
The host AP's 5GHz is not selected (in Repeater/Bridge/Client mode).
On A device is connected to the Ethernet port.
Off No device is connected to the Ethernet port.
WPS connection is in process.
On WPS connection is successful. It will turn off after 5 minutes.
WPS connection is failed.
Solid orange The signal strength is too weak (in Repeater/Bridge/Client mode).
The device is disconnected from the host network (in Repeater/
Off
Bridge/Client mode).
Indication
5
