- Page 1 ZIP HydroTap ® User Manual Affix model number label here 801912UK 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04 Page 1 of 28...
-
Page 2: Table Of Contents
When the indicator light flashes fast and continuous, a system fault has occurred. Check for details on the faults screen (see page 12). If unable to rectify, call a qualified service agent. Page 2 of 28 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04... - Page 3 Touch the blue CHILLED button to dispense chilled water. To dispense sparkling water Touch the blue CHILLED button and red BOILING button together, simultaneously to dispense sparkling water. 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04 Page 3 of 28...
-
Page 4: Classic Hydrotap G4
During heavy usage, the temperature can rise out of this range. White FILTER light Filter light off This indicates the filter is operating within its normal specified lifespan. Page 4 of 28 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04... - Page 5 To reset, return the lever to the OFF position and repeat the step. The lever has to be manually returned to the OFF position. 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04 Page 5 of 28...
-
Page 6: Arc And Cube Hydrotap ® G4
23). To reset, return the control to the OFF position and repeat the step. The control has to be manually returned to Page 6 of 28 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04... - Page 7 All three tap lights (Safety, Select and Indicator light) will flash white every 10 seconds, indicating a filter change is required. Reset the filter light see page 14. 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04 Page 7 of 28...
- Page 8 Rotate the control when the indicator light is illuminated white to dispense sparkling water. If illuminated red, or blue touch the SELECT button until the indicator light illuminates white. Page 8 of 28 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04...
-
Page 9: All-In-One Hydrotap ® G4
Tap functionality and operation Classic, Arc and Cube mixer taps operate in the same manner as the All in One mixer tap, detailed above. 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04 Page 9 of 28... -
Page 10: Lcd Screen & Menu
Note As an energy saving feature, the home screen will turn off after 5 minutes of non use. Touching the darkened LCD panel will reactivate the home screen. Page 10 of 28 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04... - Page 11 • Sleep mode options • Energy modes Settings On/Off modes • Safety • Safety lock Hot isolation • Hot/Cold dispensing • Dispense times 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04 Page 11 of 28...
- Page 12 Press [<=] button for the Reset Last Period 004.4 00.00.00 previous menu or press [HOME] button to return to the home HOME screen. Page 12 of 28 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04...
- Page 13 HydroTap G4 into calibration ® mode. With subsequent filter changes, the system reverts to the main menu. OPEN Position CLOSED Position 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04 Page 13 of 28...
- Page 14 (insulated) outlet hose from the booster is warm. Note Failing to make the correct selection for [Boost] will affect product performance. Page 14 of 28 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04...
- Page 15 Lux Sensor - OFF. When the room is subsequently darkened, below the calibrated light level, the lights will turn off after approx. 30 seconds. 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04 Page 15 of 28...
- Page 16 If you have forgotten the password, please disconnect the power and restart your HydroTap G4). ® Page 16 of 28 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04...
- Page 17 In the next screen Press [Disable] Cloud server not registered • Press [<=] button for the previous Mode: Status: menu. Hotspot disabled Disabled 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04 Page 17 of 28...
- Page 18 • Press the [Temperature] button. • To adjust the temperature, press the relevant temperature button and then use the up and down arrows. Page 18 of 28 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04...
- Page 19 Ext Filter] button. • To change filter usage, first select (Litres) or (Days), then use the up and down arrows to edit the filter usage. 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04 Page 19 of 28...
- Page 20 It is recommended to recalibrate the lux sensor after selecting any of the lux sensor options from the sleep mode menu. (See page 15 ,Lux sensor calibration).(Classic, Arc / Cube only). Page 20 of 28 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04...
- Page 21 Any attempt, during off mode, to dispense water, will bring the unit out of energy mode. The system will revert to the energy mode setting after 30 minutes of non use. 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04 Page 21 of 28...
- Page 22 Note Upon completion, all the settings can be protected by dis-allowing any setting changes by selecting ‘NO’ on the safety settings screen. Page 22 of 28 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04...
-
Page 23: Filter Maintenance
Grasp filter cartridge, depress the red lever at the top right of the filter and rotate the cartridge a quarter turn clockwise, then gently pull down. 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04 Page 23 of 28... - Page 24 Take care not to allow cloths or other soft materials to accidentally block the air inlet. Page 24 of 28 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04...
-
Page 25: Changing The Co Cylinder
Purge the gas lines, see CO purge , page 15. Regulator Note When removing hose, take care not to lose plastic olive from the fitting. 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04 Page 25 of 28... - Page 26 Test for leaks at these two points • Inspect the joint for leaks. • If any bubbles appear, the joint will need to be resealed and tested again. Page 26 of 28 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04...
-
Page 27: Home Menu Icons
(end of life). When it reaches 0% the filter warning light on the tap head will flash slowly. The filter life can be adjusted by litres and by days used. 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04 Page 27 of 28... -
Page 28: Cleaning
AU675601, AU637412, AU635979, GB0422305, GB2065848, US4354049, US5103859, US5099825 and SA2006/08043. Other patents are in force and patent applications are pending. Page 28 of 28 801912UK - Commercial Boiling, chilled and sparkling user manual - Sept 2016- v2.04...
