- Page 1 杨振华 23.02.01 更改显示屏、警告语等内容 杨振华 23.03.24 技术要求 成品尺寸：A5（143X210mm） 材质：封面封底内页80g书写纸，订装 AC60 颜色：单黑印刷 PR005-6d03A1 英文说明书（澳规BLUETTI） 杨振华 17.0303.0535-01 23.03.24...
- Page 2 AC60 Portable Power Station User Manual Please Read This Manual Before Use And Follow Its Guidance. Keep This Manual For Future Reference.
- Page 3 Warning 1. Charge the unit before first use. 2. Do not use solar panels with open circuit voltage higher than 28V. Solar input voltage range for the unit is DC 12V~28V. 3. Charge the unit when the SoC drops below 5%. If the SoC drops to 0, power off the unit and charge it for at least 30mins before restarting.
- Page 4 Thank You! Thank you for making BLUETTI a part of your family. From the very beginning, BLUETTI has tried to stay true to a sustainable future through green energy storage solutions for both indoor and outdoor use while delivering an exceptional eco-friendly experience for our homes and our world.
-
Page 5: Table Of Contents
Contents Safety Instructions General Safety Handling Storage and Usage What’s In The Box Product Overview Diagram Specifications Operation Buttons LCD Screen Charging Discharging Connect AC60 and B80 BLUETTI App Appendix FAQs Troubleshooting Abbreviations... -
Page 6: Safety Instructions
The Safety Requirements provided herein are for illustrative purposes that include but are not limited to those listed in this manual. Actual operation shall comply with all applicable safety standards. If you have any questions, feel free to contact BLUETTI support or your local BLUETTI dealers. 1.1. General Safety •... - Page 7 Do not move the unit during operation as the vibrations and shocks associated with movement may cause damage to the internal hardware. • In case of malfunction, turn off the unit immediately and contact BLUETTI support or your local BLUETTI dealers if this manual cannot adequately explain the malfunction to you.
-
Page 8: Handling
It is recommended to charge the unit via an AC source. If charging via solar energy, ensure that your solar system provides an output of more than 100W. BLUETTI shall not be liable for any equipment damage caused by the violation of above instructions. -
Page 9: What's In The Box
2. What’s In The Box Standard Packaging Item Picture Qty. Portable Power Station AC Charging Cable (16AWG, 1800mm) Car Charging Cable ((16AWG, 720mm) Solar Charging Cable (16AWG, 1500mm) User Manual Warranty Card Quality Certificate JUST POWER ON... - Page 10 Optional Item Picture TYPE-C Cable (5A/100W, 2m) Cigarette Lighter to 5521 Cable (For 12V devices with 5521 port, such as routers, cameras, etc.) Cigarette Lighter to Clamp Cable (Charging lead-acid battery via the cigarette lighter port) Lead-acid battery charging cable (DC7909) JUST POWER ON...
-
Page 11: Product Overview
3. Product Overview 3.1 Diagram As a portable power station, AC60 weighs only 9.1 kg, yet features a 600W pure sine wave inverter and 403.2Wh LiFePO4 battery pack, enough to run most of your essentials for hours. LiFePO4 cells, the safest chemistry available, together with advanced Battery Management System (BMS), give you the highest level of security. -
Page 12: Specifications
3.2 Specifications Model AC60-JP AC60-US AC60-CN AC60-EU AC60-AU General Battery Capacity 403.2Wh Cell Type LiFePO4 Net Weight About 9.1kg/20.06lbs Dimensions (L*W*H) 290mm×205mm×234mm/11.42in×8.07in×9.21in Charging Temperature C～40 C/32°F～104°F -20°C～40°C(-20°C～30°C: 600W Max.; 30°C～40°C: 500W Max.) Discharging Temperature -4°F～104°F(-4°F～86°F: 600W Max.; 86°F～104°F: 500W Max.) Storage Temperature C～40... -
Page 13: Operation
4.1.1. Power ON/OFF • Press the PWR button to start the AC60. When AC60 is on, press this button to turn on/off the LCD screen. Press and hold the button for more than 2 seconds to turn off the AC60. - Page 14 Grid Enhancement mode: By default, the Grid Enhancement mode is disabled. Please turn it on directly in the BLUETTI app. This mode ensures that the AC60 has a stable and continuous AC input, as it allows AC60 to adapt to voltage fluctuations and waveform distortion of an AC source.
-
Page 15: Lcd Screen
4.2. LCD Screen ① ⑧ ⑮ DC Input Expansion battery 1 Short circuit alert ② ⑨ ⑯ Bluetooth Expansion battery 2 Overload alert ③ ⑩ ⑰ Wireless charging Input power Remaining time indicator ④ ⑪ ⑱ Battery capacity Power Lifting mode ⑤... -
Page 16: Charging
Turbo and silent modes can be enabled in BLUETTI app. BLUETTI’s AC charging mode guide is as follows: 1) Turbo charging comes in handy when you need AC60 to be replenished in short time. 2) Standard charging is more friendly to AC60’s battery. - Page 17 4.3.2.Solar Charging Connect the solar panels (in series or parallel) to AC60 via the solar charging cable. Note: Please make sure your solar panels comply with: Voc: 12V~28V Input Current: 8A Max. Input Power: 200W Max. Warning: The open circuit voltage of solar panels cannot exceed 28V, otherwise it will damage the device.(Note: This is not covered in the warranty.)
-
Page 18: Discharging
The operation time of AC60 is subject to many factors, such as ambient temperature, discharge rate, battery capacity, altitude, load characteristics, etc. 4.4.1.AC Output AC60 has 2 AC output ports, providing a total of up to 600W AC power. It can also handle a surge of 1200W. 4.4.2.DC Output •... -
Page 19: Connect Ac60 And B80
(AC60+2*B80) (AC60+1*B80) 4.6 BLUETTI App Scan the QR code below or search "BLUETTI" in the App Store or Google Play to down- load the BLUETTI app. AC60 supports Bluetooth connection. Once connected, the AC60 can be accessed and controlled on a mobile phone or other smart devices. For more details, please refer to BLUETTI APP INSTRUCTIONS. -
Page 20: Appendix
Please evaluate the total constant load of your devices. If it doesn't exceed the Max. output power of AC60 (600W), you can use this power station to run your devices. Please note that if the total load exceeds the limit, but the loads on AC output is lower than 600W, the inverter will turn off the DC output only. -
Page 21: Troubleshooting
When should I use the Grid Enhancement mode? This mode is handy when charging the AC60 via an unstable AC source, such as an unreliable grid or generator. E.g. If you change the generator's output while charging the AC60, the voltage dip will also cause the charge to fail. -
Page 22: Abbreviations
5.3 Abbreviations • MPPT: Maximum Power Point Tracking • SoC: State of Charge • UPS: Uninterruptible Power Supply • AC: Alternating Current • DC: Direct Current • PV: Photovoltaic (Solar Panels) • DoD: Depth of Discharge JUST POWER ON... - Page 24 For more information, please visit: Web: https//www.bluettipower.com @ BLUETTI Support @ BLUETTI Official @ bluetti_inc @bluetti.inc @bluetti_official service@bluettipower.com...
