PETROL
CHAINSAW
25.4cc-305mm (12")
INSTRUCTION MANUAL
SPECIFICATIONS
Engine:
25.4cc 2-Stroke
Output Power:
0.9kw
No Load Idling Motor Speed: 3,500/min
Max. No Load Motor Speed: 11,000/min
Bar Length:
305mm (12")
Bar Type:
Sprocket Nose
Chain Brake:
Automatic
Oil Feed:
Automatic Pump
Fuel Mixture:
40:1
Chain Oil:
Standard Chain Bar Oil
ozito.com.au
1
WHAT'S IN THE BOX
Petrol Chainsaw
Guide Bar Cover
Socket Wrench and Screw-
driver
Chain File
Oil Mix Bottle
PCS-305A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ozito PCS-305A
Summary of Contents for Ozito PCS-305A
- Page 1 No Load Idling Motor Speed: 3,500/min driver Max. No Load Motor Speed: 11,000/min Bar Length: 305mm (12”) Bar Type: Sprocket Nose Chain Brake: Automatic Oil Feed: Automatic Pump Chain File Fuel Mixture: 40:1 Chain Oil: Standard Chain Bar Oil ozito.com.au Oil Mix Bottle PCS-305A...
-
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION 1: FUEL PETROL CHAINSAW 1 Choke control 6 Chain Tension Screw 2 Exhaust 7 Chain Drive Cover Nut WARNING!: Petrol is very flammable. Avoid smoking or 3 Chain Drive Cover 8 On/Off Switch causing any sparks or flames near fuel. Make sure that 4 Throtle Safety Lock 9 Guide Bar you stop the motor and allow it to cool before refuelling... -
Page 3: Operation
OPERATION 2. CHAIN BAR OIL 3. CHAIN BRAKE & CHOKE Chain brake / Anti kickback guard • Only use oil that is expressly labeled “Chain Bar Oil”. The chain brake operates automatically in the event of kick back. Kick back occurs if the chain catches on the wood being cut. -
Page 4: Cold Starting
4. COLD STARTING 5. CUTTING 1. Set the “I” ON switch to ON “I”. 2. Make sure the brake is ON when starting for 1. When ready to start cutting, release the brake, by pulling the safety, by pushing the front front guard back firmly towards the rear of the chainsaw guard forward 3. -
Page 5: Hot Starting
Recheck the tension after a few minutes of cutting front guard back firmly as the chain may stretch initially after use. A loose chain towards the rear of the may cause wear to both the chain and the guide bar and become a major safety hazard. PCS-305A... -
Page 6: Maintenance
The carburettor is factory set and should not require adjustment. Changes in operating conditions may require fine tuning of the carburettor. A special tool is required for making these adjustments. Contact Ozito Customer Service for advice and instructions. Aus: 1800 069 486... -
Page 7: Description Of Symbols
To receive full value from the warranty, the operator must maintain the chainsaw as instructed in this manual. Ozito Industries will not be responsible for any damage or injuries caused by repair of the tool by an unauthorised person or mishandling or mistreatment of the tool. -
Page 8: Safety Warnings
SAFETY WARNINGS RISK OF EXPLOSION OR FIRE c) Remove any adjusting key or wrench before turning the tool on. A wrench or a key that is left attached to a rotating part of the petrol tool may result in personal What can happen: injury. -
Page 9: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 1215...
