Ozito Power X Change PXCCSS-0182 Instruction Manual

Ozito Power X Change PXCCSS-0182 Instruction Manual

Brushless chainsaw

Advertisement

BRUSHLESS
CHAINSAW
INSTRUCTION MANUAL
SPECIFICATIONS
Input:
2 x 18V
Bar Length:
356mm (14")
Max. Cutting Length:
330mm
Max. Chain Speed:
15m/s
Chain Pitch:
9.53mm (3/8")
Chain Gauge:
1.1mm (0.043")
Oil Tank Capacity:
225ml
Weight (Tool Only):
4.1kg
ozito.com.au
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
OZITO
Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
WARRANTY
The benefits provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty Warranty excludes consumable parts, for example: guide bar, chain
and included accessories.
STANDARD EQUIPMENT
Brushless Chainsaw
Guide Bar Cover
Chain
Guide Bar
PXCCSS-0182
0918

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power X Change PXCCSS-0182 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ozito Power X Change PXCCSS-0182

  • Page 1 Oil Tank Capacity: 225ml Guide Bar Weight (Tool Only): 4.1kg ozito.com.au PXCCSS-0182 WARRANTY IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU The benefits provided under this warranty are in addition to other rights and remedies which are available to you at law.
  • Page 2: Know Your Product

    If it does not fit, it can be adjusted BATTERY & CHARGER slightly by turning the dial. This tool is compatible with all battery and chargers from the Ozito 3/8” LP Power X Change Range. 3/8” LP ONLINE MANUAL 5. Attach the side cover and secure it with the Scan this QR Code with your side cover lock.
  • Page 3 2. OIL Adjusting the chain tension IMPORTANT: ONLY USE OIL THAT IS EXPRESSLY LABELLED 1. Loosen the guide bar lock knob “CHAIN BAR OIL”. slightly, by rotating it in an anti clockwise direction. 1. Remove the chain bar oil cap. 2.
  • Page 4: Operation

    OPERATION 3. INSERTING & REMOVING BATTERIES 4. SWITCHING ON/OFF Switching ON Inserting the Batteries 1. Pull the hand guard/chain IMPORTANT: ALWAYS USE 2 BATTERIES OF THE SAME brake towards you. CAPACITY AND SAME CHARGE STATE WITH THE CHAINSAW. 1. Align the ribs of the battery with the recess in the chainsaw.
  • Page 5 APPLICATIONS 5. CUTTING Felling a Tree CAUTION: FIRST TIME USERS SHOULD, AS A MINIMUM PRACTISE, CUT LOGS ON A SAW-HORSE OR CRADLE WARNING!: FELLING A TREE SHOULD ONLY BE DONE BY TRAINED OPERATORS. 1. Press the bucking spikes against Decide the direction in which you wish the timber ensuring the chain the tree to fall, taking into account is not making contact with the...
  • Page 6: Maintenance

    TROUBLESHOOTING MAINTENANCE PROBLEM CAUSE REMEDY WARNING: BEFORE CLEANING YOUR CHAINSAW OR CARRYING OUT ANY MAINTENANCE PROCEDURE, Chainsaw will not Chain brake Disengage brake MAKE SURE THE BATTERY REMOVED TO PREVENT work. engaged ACCIDENTAL STARTING. Batteries are low in Charge both charge batteries CAUTION:...
  • Page 7: Spare Parts

    Chain Replacement: YOUR BATTERY CHARGER. The chain can be purchased through Ozito spare parts or from your local Bunnings Before using the charger read all instructions and cautionary markings on the charger, battery pack and the product Warehouse. The correct chain can be purchased by matching the pitch, gauge and using the battery pack.
  • Page 8: Electrical Safety

    The power supply for this products charger should be protected by a residual current device (rated at 30mA Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. or less). A residual current device reduces the risk of electric shock.
  • Page 9: Battery Safety Warnings

    Save these instructions and other documents supplied with this tool for future reference. DESCRIPTION OF SYMBOLS Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. This tools charger is double insulated therefore no earth wire is required.
  • Page 10 Australia 1800 069 486 tool) for the battery to reach its optimum performance / runtime. This battery is compatible with chargers from the 18V Ozito Power X Change range New Zealand 0508 069 486 available through your local Bunnings Warehouse: Product availability may differ.
  • Page 11 Save these instructions and other documents supplied with this tool for future reference. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. DESCRIPTION OF SYMBOLS This charger is double insulated therefore no earth wire is required.
  • Page 12: Charging A Battery

    BOTH (Flashing) The battery is deffective, charging is no longer on the tool. possible. Do not charge. Contact Ozito Customer • If the tool shows signs of damage or defects caused by or resulting from Service. abuse, accidents or alterations.
