- Page 1 PXCCSS-0182U Original operating instructions Cordless Chainsaw Art.-Nr.: 45.017.82 I.-Nr.: 11019 Anl_PXCCSS_0182U_SPK7.indb 1 Anl_PXCCSS_0182U_SPK7.indb 1 27.11.2019 14:48:02 27.11.2019 14:48:02...
- Page 2 - 2 - Anl_PXCCSS_0182U_SPK7.indb 2 Anl_PXCCSS_0182U_SPK7.indb 2 27.11.2019 14:48:03 27.11.2019 14:48:03...
- Page 3 - 3 - Anl_PXCCSS_0182U_SPK7.indb 3 Anl_PXCCSS_0182U_SPK7.indb 3 27.11.2019 14:48:04 27.11.2019 14:48:04...
- Page 4 min. - 4 - Anl_PXCCSS_0182U_SPK7.indb 4 Anl_PXCCSS_0182U_SPK7.indb 4 27.11.2019 14:48:07 27.11.2019 14:48:07...
- Page 5 - 5 - Anl_PXCCSS_0182U_SPK7.indb 5 Anl_PXCCSS_0182U_SPK7.indb 5 27.11.2019 14:48:10 27.11.2019 14:48:10...
- Page 6 - 6 - Anl_PXCCSS_0182U_SPK7.indb 6 Anl_PXCCSS_0182U_SPK7.indb 6 27.11.2019 14:48:11 27.11.2019 14:48:11...
- Page 7 - 7 - Anl_PXCCSS_0182U_SPK7.indb 7 Anl_PXCCSS_0182U_SPK7.indb 7 27.11.2019 14:48:12 27.11.2019 14:48:12...
-
Page 8: Table Of Contents
Table of contents 1. Safety regulations 2. Layout and items supplied 3. Proper use 4. Technical data 5. Before starting the equipment 6. Operation 7. Working with the chainsaw 8. Cleaning, maintenance and ordering of spare parts 9. Notes on environmental protection / disposal 10. -
Page 9: Safety Regulations
Danger! d) Do not abuse the cord. Never use the When using the equipment, a few safety pre- cord for carrying, pulling or unplugging cautions must be observed to avoid injuries and the power tool. Keep cord away from damage. Please read the complete operating heat, oil, sharp edges or moving parts. - Page 10 4) Power tool use and care connection from one terminal to another. a) Do not force the power tool. Use the cor- Shorting the battery terminals together may rect power tool for your application. The cause burns of a fi re. correct power tool will do the job better and d) Under abusive conditions, liquid may be safer at the rate for which it was designed.
- Page 11 5. Do not throw battery packs into an open fi re. temperature before commencing with the There is a risk of explosion! charging. 6. Do not ignite the battery pack or expose it to 7. Do not over-charge batteries. Do not ex- fi...
- Page 12 ambient temperature of 10-40°C. Store your hand on the front handle. Holding the chain lithium-ion battery pack in a cool, dry place at saw with a reversed hand confi guration incre- a temperature of 10-20°C. Protect them from ases the risk of personal injury and should humidity and direct sunlight.
-
Page 13: Layout And Items Supplied
• Causes and operator prevention of kickback: Damage to hearing if no suitable ear protec- Kickback may occur when the nose or tip of the tion is applied. • guide bar touches an object, or when the wood Health damage caused by hand-arm vibra- closes in and pinches the saw chain in the cut. -
Page 14: Proper Use
4. Technical data 18. Charger (not included in delivery) 19. Adapter plate Motor power supply: ....... 36 V DC 2.2 Items supplied Idle speed n : ......max. 8200 min Please check that the article is complete as Cutting speed at rated rpm: ....max. 15 m/s specifi... -
Page 15: Before Starting The Equipment
Keep the noise emissions and vibrations to a sion. The saw chain is correctly tensioned if it minimum. can be lifted around 3-4 mm in the middle of • Only use appliances which are in perfect wor- the cutter rail (Fig. 9). •... -
Page 16: Operation
• Close the oil tank cover. (Fig. 1/Item 6). You can then release the safe- ty lock-off. 5.4 Charging the Li battery pack (Fig. 11-12) The battery is protected from exhaustive dischar- Switching off ge. An integrated protective circuit automatically Release the ON/OFF switch (Fig. -
Page 17: Working With The Chainsaw
7. Working with the chainsaw 7.2 Description of the correct procedures for basic use of the chainsaw Felling a tree (Figs. 14-17) 7.1 Preparations If two or more persons are working at the same To ensure that you can work safely, check the fol- time on felling and cutting back then the minimum lowing points before every use: distance between the tree being felled and the... - Page 18 or it starts to lean back and traps the saw chain, When working with the saw on a slope, always interrupt the felling cut and insert wedges made position yourself at a higher point on the slope of wood, plastic or aluminum to open out the cut above the tree as shown in Fig.
-
Page 19: Cleaning, Maintenance And Ordering Of Spare Parts
Cutting wood which is under tension Checking the automatic chain lubrication Special care is required when cutting wood which You should check the operation of the automatic is under tension. Wood which is under tension chain lubrication system on a regular basis in or- from which it is released by cutting may in some der to guard against overheating and the associ- cases react completely unpredictably and uncont-... -
Page 20: Storage
10. Storage Store the equipment and accessories out of children’s reach in a dark and dry place at above freezing temperature. The ideal storage tempe- rature is between 5 and 30 °C. Store the electric tool in its original packaging. - 20 - Anl_PXCCSS_0182U_SPK7.indb 20 Anl_PXCCSS_0182U_SPK7.indb 20... -
Page 21: Troubleshooting
11. Troubleshooting Danger! Before troubleshooting, switch off the equipment and pull out the battery. The table below contains a list of fault symptoms and explains what you can do to remedy the problem if your tool fails to work properly. If the problem still persists after working through the list then please con- tact your nearest service workshop. -
Page 22: Charger Indicator
12. Charger indicator Indicator status Explanations and actions Red LED Green LED Off Flashing Ready for use The charger is connected to the mains and is ready for use; there is no battery pack in the charger Off Charging The charger is charging the battery pack in quick charge mode. The char- ging times are shown directly on the charger. -
Page 23: Permissible Cutter Sets
13. Permissible cutter sets Length of cutter set 305 mm (12‘’) 356 mm (14‘’) 405 mm (16‘’) Max. cutting length 280 mm 330 mm 380 mm Oregon Chain 90PX045X 90PX052X 90PX056X Chain bar 566655 577293 112329 (124MLEA041) (144MLEA041) (164MLEA041) Kangxin Chain 3/8.043X45DL 3/8.043X52DL... - Page 24 For EU countries only Never place any electric power tools in your household refuse. To comply with European Directive 2012/19/EC concerning old electric and electronic equipment and its implementation in national laws, old electric power tools have to be separated from other waste and disposed of in an environment-friendly fashion, e.g.
- Page 25 Service information We have competent service partners in all countries named on the guarantee certifi cate whose contact details can also be found on the guarantee certifi cate. These partners will help you with all service re- quests such as repairs, spare and wearing part orders or the purchase of consumables. Please note that the following parts of this product are subject to normal or natural wear and that the following parts are therefore also required for use as consumables.
- Page 26 Warranty certifi cate Dear Customer, All of our products undergo strict quality checks to ensure that they reach you in perfect condition. In the unlikely event that your device develops a fault, please contact our service department at the address shown on this guarantee card.
- Page 27 EÚ a noriem pre výrobok Lýsir uppfyllingu EU-reglna og annarra staðla vöru a cikkekhez az EU-irányvonal és Normák szerint a következő konformitást jelenti ki Cordless Chain Saw PXCCSS-0182U (Ozito) 2014/29/EU 2006/42/EC Annex IV 2005/32/EC_2009/125/EC Notifi ed Body: TÜV SÜD Product Service GmbH, Ridlerstraße 65, 2014/35/EU D-80339 München, Germany...
- Page 28 EH 11/2019 (01) Anl_PXCCSS_0182U_SPK7.indb 28 Anl_PXCCSS_0182U_SPK7.indb 28 27.11.2019 14:48:16 27.11.2019 14:48:16...
