PETROL
CHAINSAW
25.4cc - 254mm (10")
INSTRUCTION MANUAL
SPECIFICATIONS
Engine:
25.4cc 2 Stroke
Power:
0.7 kW
Bar:
254mm (10")
Max. Cutting Capacity:
200mm (8")
Chain Pitch:
9.525mm (3/8")
No Load Speed:
11,000/min
Chain Speed:
21 m/s
Fuel Mix
40:1
Fuel Tank Capacity:
230ml
Chain Oil Tank Capacity:
160ml
Tool Weight:
3.8 kg
ozito.com.au
1
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO
Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
WARRANTY
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
1 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 12 months from
the original date of purchase. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example:
filters, spark plugs, chains and included accessories.
WARNING
The following actions will result in the warranty being void.
• Professional, Industrial or high frequency use.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
STANDARD EQUIPMENT
Petrol Chainsaw
Chain Bar Cover
Fuel Mixing Bottle
Spark Plug Wrench
Hex Key
PCS-254
0419

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCS-254 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ozito PCS-254

  • Page 1 Tool Weight: 3.8 kg ozito.com.au Spark Plug Wrench Hex Key PCS-254 WARRANTY IN ORDER TO MAKE A CLAIM UNDER THIS The benefits provided under this warranty are in addition WARRANTY YOU MUST RETURN THE PRODUCT to other rights and remedies which are available to you at law.
  • Page 2: Know Your Product

    KNOW YOUR PRODUCT SETUP & PREPARATION PETROL CHAINSAW 1. ADJUSTING THE CHAIN TENSION 1. Side Cover 6. Chain Drive Cover Nuts 2. Choke Control 7. Chain Tension Screw 3. Throttle Safety Release 8. Chain WARNING! WEAR PROTECTIVE GLOVES AT ALL 4.
  • Page 3 2. CHAIN BRAKE & LUBRICATION 3. FUEL Chain brake/anti kickback guard START WARNING! PETROL IS VERY FLAMMABLE. DO NOT SMOKE OR CAUSE ANY SPARKS The chain brake operates automatically in the event of kick OR FLAMES NEAR FUEL. MAKE SURE THAT back.
  • Page 4: Operation

    OPERATION 4. STARTING & STOPPING Cold starting Warm starting 1. Make sure the switch is in 1. Set the ignition switch to the ON position. “On (I)”. 2. For safety reasons, make START sure the brake is ON when starting. To apply the brake, START push the chain brake 2.
  • Page 5: Cutting Methods

    Position your body to the left of the chainsaw so if it kicks back uncontrollably, it goes over your right shoulder, never stand in the cutting line of the saw. • Keep a firm grip with your left hand on the front handle, with your thumb securely below the handle. PCS-254...
  • Page 6: Maintenance

    APPLICATIONS (cont.) MAINTENANCE (cont.) 4. Before fitting chain, ensure the 6. CUTTING METHODS (CONT.) guide bar is positioned over the threaded mounting on the chainsaw. Pruning WARNING! DO NOT USE AN UNSTABLE FOOTHOLD OR LADDER. DO NOT OVERREACH. DO NOT SAW ABOVE SHOULDER HEIGHT. 5.
  • Page 7: Description Of Symbols

    1. Loosen the filter cover knob and remove the filter cover. Chain Replacement: 2. Pull the spark plug lead off the The chain can be purchased through Ozito spare parts or from your spark plug end. local Bunnings Warehouse. The correct chain can be purchased by 3.
  • Page 8: Additional Safety Instructions For Chainsaws

    SAFETY INSTRUCTIONS RISK OF EXPLOSION OR FIRE dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries. What can happen: c) Remove any adjusting key or wrench before turning the tool on. A wrench or a key •...
