Ozito ECS-406A Instruction Manual

2200w 406mm
Hide thumbs
Table of Contents

Advertisement

Quick Links

ELECTRIC
CHAINSAW
2200W 406mm
INSTRUCTION MANUAL
SPECIFICATIONS
Power:
2200W
Voltage:
220V – 240V ~ 50Hz
Bar Type:
Oregon 406mm (16")
Chain Pitch:
9.53mm (3/8")
Sharpening File:
3.96mm (5/32")
Chain Speed:
15m/s
Oil Feed:
Automatic
Oil Tank Capacity: 160ml
Weight:
5.6kg
ozito.com.au
WHAT'S IN THE BOX
Electric Chainsaw
Guide Bar Cover
Chain
Guide Bar
ECS-406A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECS-406A and is the answer not in the manual?

Questions and answers

Related Manuals for Ozito ECS-406A

Summary of Contents for Ozito ECS-406A

  • Page 1 Guide Bar Cover SPECIFICATIONS Power: 2200W Voltage: 220V – 240V ~ 50Hz Bar Type: Oregon 406mm (16”) Chain Pitch: 9.53mm (3/8”) Sharpening File: 3.96mm (5/32”) Chain Chain Speed: 15m/s Oil Feed: Automatic Oil Tank Capacity: 160ml Weight: 5.6kg ozito.com.au Guide Bar ECS-406A...

  • Page 2: Know Your Product

    KNOW YOUR PRODUCT ASSEMBLY ELECTRIC CHAINSAW 1. GUIDE BAR & CHAIN 1. Power cord 9. Chain 2. Cord retainer 10. Bucking spikes WARNING! ENSURE THE CHAINSAW IS TURNED 3. Oil level window 11. Chain brake OFF & DISCONNECTED FROM THE POWER 4.

  • Page 3: Setup & Preparation

    3mm gap is the ideal tension SETUP & PREPARATION 3mm gap is the ideal tension 2. CHAIN TENSION 3. LUBRICATION WARNING! TO PREVENT ACCIDENTAL STARTING, NOTE: ONLY USE OIL THAT IS EXPRESSLY LABELLED ENSURE THAT THE CHAINSAW IS DISCONNECTED “CHAIN BAR OIL”. FROM THE POWER SUPPLY BEFORE MAKING ANY ADJUSTMENTS.

  • Page 4: Operation

    OPERATION 4. CORD RETAINER 5. CHAIN BRAKE The cord retainer is used to “anchor” an extension cord when it is Chain brake connected to the power lead of the tool. It prevents the extension cord The chain brake operates from being accidentally disconnected from the chainsaw’s power cord automatically in the event BRAKE ON or shaken loose during use.

  • Page 5: Switching On/Off

    – Position your body to the left of the chainsaw so if it kicks back uncontrollably, it goes over your right shoulder, never stand in the cutting line of the saw. – Keep a firm grip with your left hand on the front handle, with your thumb securely below the handle. ECS-406A...

  • Page 6: Cutting Applications

    APPLICATIONS MAINTENANCE 8. CUTTING APPLICATIONS 9. GENERAL MAINTENANCE Felling a tree WARNING! ENSURE THE CHAINSAW IS TURNED OFF & DISCONNECTED FROM THE POWER WARNING! FELLING A TREE SHOULD ONLY BE SUPPLY BEFORE PERFORMING ANY OF THE DONE BY TRAINED OPERATORS. FOLLOWING OPERATIONS.

  • Page 7: Description Of Symbols

    SPARE PARTS Chain Replacement: The chain can be purchased through Ozito spare parts or from your local Bunnings Warehouse. The correct chain can be purchased by matching the pitch, gauge and number of links as shown below: 9.53mm(3/8)
  • Page 8 Tool: 2200W Electric Chainsaw SPARE PARTS Model No. ECS-406A The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. Switch 450172201002 Oil box cap...

  • Page 9: Electrical Safety

    ELECTRICAL SAFETY WARNING! When using mains-powered tools, basic safety precautions, including The power supply for this product should be protected by a residual current device (rated at the following, should always be followed to reduce risk of fire, electric shock, 30mA or less).

  • Page 10: Warranty

    • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0814...
