Evolve™ LED Area Light
Scalable Fixtures (EAS)
Section 1: Light Engine(s) Out
Incoming
leads to
fixture
Pull back gently
on leads. They should
not disengage
Pull back gently on leads.
They should not disengage
EASC Assembly View
*Actual shape and color of connectors may vary.
(continued)
Troubleshooting
and Repair Guide
Outgoing
Primary disconnect
leads to
fixture
