Summary of Contents for KingSlim D1 PRO
- Page 1 D1 PRO D A S H C A M D1 PRO V2.1...
- Page 2 User Agreement By purchasing Kingslim dash cams, you agree to Kingslim's terms and conditions, which include precautions, user warnings, and warranty coverage. If you do not agree to any of these terms mentioned in this manual for any reason, you may return the product unused and in its original packaging within the stated return window for a full refund.
- Page 3 Warnings 1. Please take note of safety warnings and regulations as failure to comply may result in serious injury or death. 2. Avoid placing the camera on top of the instrument panel or in front of the airbag as it may fall and cause harm. 3.
-
Page 4: Table Of Contents
Start Recording -------------------------------------------------------------------------------- 19 Playback Videos ------------------------------------------------------------------------------- 22 1. Playback on the dash cam ---------------------------------------------------------------- 22 2. Playback on a computer------------------------------------------------------------------- 23 3. Playback on the Kingslim APP------------------------------------------------------------ 23 Camera Settings ------------------------------------------------------------------------------- 24 1. Video Settings -------------------------------------------------------------------------------- 24 2. System Settings ------------------------------------------------------------------------------ 26 Use the Kingslim APP ------------------------------------------------------------------------ 29 1. -
Page 5: Camera Specifications
Camera specifications LCD touch screen 2-inch IPS LCD screen Video resolution 4K, 4K+1080P, 2K+1080P Lens aperture F1/8 External GPS module Wifi Built-in Video format Memory card Class 10 U3 or higher, capacity up to 128GB G-sensor Built-in 3-axis gyroscope Light source frequency 60Hz, 50Hz Loop recording Seamless loop recording... -
Page 6: Led Indicators
LED Indicators Blue light staying on Battery fully charged+not recording Blue light flashing Battery fully charged+ recording Red and purple lights Charging+recording flashing alternatively Purple light staying on Charging Tip: Dash cams are electronic devices that contain various components, including a processor, memory, camera lens, and other circuitry. -
Page 7: Getting Started
Getting Started Please read and understand warnings & safety instructions before operating. 1. Inserting Memory Card To record video, you need to insert a memory card, and complete the formatting process. We recommend you use a Class 10 U3 or higher memory card of well-known brands at a maximum of 128GB. -
Page 8: Setting Time Zone
4. Recording KINGSLIM 4K D1 Pro dash cam is programmed to turn on and start recording automatically when it receives power. It will also start recording after you finish changing settings. To pause recording, please press . When unplugged, this dash cam will also automatically stop recording, safely save the last video, and shut down within 5 seconds. -
Page 9: What's In The Box
What’s in the box D1 PRO D1 Pro Dash Cam Car Charger with External GPS Suction Cup Mount Electrostatic Sticker Car Crowbar Cable Clip Quick Start Guide ��... -
Page 10: Camera Overview
Camera Overview Mini USB Power Port Bracket Slot Power Button Microphone Memory Card Slot D1 PRO Front Camera IR LED & Indicator Light Speaker Inside Camera Screen Settings Button Wifi Button Reset Hole ��... -
Page 11: Icon Introduction
Icon Introduction Video Time Start Recording Parking Monitor Date Microphone Indicator Time Power Status Lock Video Recording Resolution Audio Recording (Mute/Unmute) Setup / Wifi Snapshot Playback Stop Recording Switch View Modes ��... - Page 12 Video Settings Backward System Settings Forward Backward Confirm Down ��...
-
Page 13: Installation
To record videos, you need a compatible memory card (sold separately). We recommend you use a Samsung/Sandisk/Kingston Class 10 U3 or high memory card for your D1 Pro dash cam. This dash cam supports a memory card of up to 128GB. Warm tip: 1. - Page 14 (2) Format the memory card You need to complete the formatting process in the camera each time you insert the card. To do this, please access the formatting screen. In case you have not yet done so, an error message will appear prompting you to insert the memory card. Please follow the instructions below to format the memory card.
- Page 15 ③ On this screen, press the OK button to enter the formatting screen, press the Down button to “OK”, and then press the OK button to complete formatting. The system will then exit the menu automatically. All data will be deleted Cancel Kind reminder: All data will be deleted after formatting.
-
Page 16: Install The Dash Cam On The Windshield
Clean the area thoroughly with a microfiber cloth to remove any dust, dirt, or oil that could affect the suction cup mount's grip. ③ Attach the suction cup mount Attach the suction cup mount onto the dash cam by aligning the notches or grooves. D1 PRO D1 PRO ��... - Page 17 D1 PRO D1 PRO ④ Place the dash cam. First, remove the film from the GPS electrostatic sticker, and apply it to the windshield. Second, peel off the other film from the sticker, then attach the dash cam onto the sticker.
-
Page 18: Charging
(2) Turn your camera ON/OFF Auto Power ON: KINGSLIM D1 Pro dash cam is designed to turn ON automatically when it receives power, i.e. when the car engine is started. Auto Power OFF: The camera is also pre-configured to turn OFF automatically within a few seconds when the power gets disconnected, i.e. - Page 19 (3) Install the hardwire kit Installing the hardwire kit helps prevent the camera battery from draining the car battery thanks to its smart low voltage protection system. Above all, installing the hardwire kit allows you to connect the camera directly to the vehicle's electrical system, providing a continuous and stable power supply.
-
Page 20: Start Recording
Start Recording To use the dash cam, you can select either single or dual recording mode. However, before doing so, you must first set the desired resolution. 1. 4K Single Recording (Front Camera). ① After turning on the camera, press the button to stop recording. - Page 21 ③ After you have successfully set the resolution, press the Back button twice to go back to the preview screen. The dash cam will be in single recording mode. In this mode, press the Record button, the front camera will record 4K videos. One-press quick recording: Press to switch to single (front) recording, and...
- Page 22 2K+1080P 4K+1080P ③ After you have successfully set the resolution, press the Back button twice to go back to the preview screen. The dash cam will be in dual recording mode. In this mode, press the Record button, the front and cabin cams will record 2K/4K and 1080P videos respectively.
-
Page 23: Playback Videos
Playback Videos 1. Playback on the dash cam You can choose to play back normal videos, locked videos, parking monitor videos, and photos on the dash cam. After turning on the camera, press the button to stop recording, and press to enter the playback screen, then press the Down button to playback files stored in the memory card. -
Page 24: Playback On A Computer
GPS data won't show if you playback the video on your own player. 3. Playback on the Kingslim APP You can also playback videos on the Kingslim APP after connecting your dash cam to the APP. For more details, please refer to Download the Kingslim APP→Playback Videos on the APP. -
Page 25: Camera Settings
Camera Settings After turning on the camera, press the button to stop recording. 1. Video Settings To enter the video settings screen, first, press the Setup button to enter the camera settings screen. Second, choose the first button, then press the OK button to confirm. - Page 26 (4) WDR (Wide Dynamic Range) Off, On (The default setting is Off) You can turn WDR on or off. WDR is ideal for use in high-contrast scenes, allowing for more details in images. (5) Record Audio Off, On (The default setting is On) You can choose to record videos with or without audio.
-
Page 27: System Settings
2. System Settings Press the Setup button to enter the camera settings page, choose then press the OK button to enter the system settings page. (1) Screen Saver Off, 30 Sec, 1 Minute, 2 Minutes (The default setting is Off) On the system settings screen, press the Down button to find “Screen Saver”, then press the OK button to enter the screensaver settings screen. - Page 28 (6) Beep Sound Off, On (The default setting is on) You can turn beep sounds on or off. (7) Language English, 简体中文, 繁体中文, Français, Español, Deutsc, Italiano, 日本語, 한국어 (The default setting is English) You can set the system language for your dash cam. (8) Parking Monitor Off, On (The default setting is Off) When the car engine is off, the dash cam will enter parking monitor mode...
- Page 29 (12) Speed Unit KM/H, MP/H (The default setting is MP/H) You can choose your desired speed unit. (13) GPS Information To check if the GPS is working well, you can refer to the GPS information displayed on the screen below. The signals your dash cam is receiving is indicated by the number of the bars, with larger numbers indicating a stronger signal.
-
Page 30: Use The Kingslim App
Use the Kingslim APP Once you have successfully connected your dash cam to the Kingslim APP via the camera’s Wifi, you will be able to access the camera, view and download videos via the APP. You can also control the camera to capture or change the camera settings using the phone APP. - Page 31 4G signal of your phone is blocked, but you can ignore it and continue the app connection. (4) Access the Kingslim app. To do this, open the Kingslim APP, then tap the “New Account” icon to enter your email and get a verification code for login.
-
Page 32: Playback Videos On The App
(5) Connect to the Kingslim app. To do this, tap "Add Recorder" to add your camera model, then wait for a few seconds till the APP loads past the Connecting screen to enter the preview screen. Your dash cam will be successfully connected to the Kingslim APP. -
Page 33: Download Videos From The App
4. Download videos from the APP (1) Tap the “Video set” icon to enter the video menu. NVT_ **** (2) Tap the “Select” icon in the upper right corner, and choose the video you want to download. ��... - Page 34 (3) Tap the Download icon in the bottom left corner to download the video. (4) Wait for the completion of the download progress, the video will be saved to your phone's album. You can tap it for playback or forward it to social media. ��...
-
Page 35: General Faq
General FAQ Warm Tips: For any product issues, please feel free to contact us anytime for technical support. 1. What to do if the dash cam does not turn on anymore? ➀Check if the indicator light on the car charger turns on when your dash cam is plugged in. - Page 36 4. What to do if the KINGSLIM APP can't connect to your dash cam? ① Make sure you have installed the up-to-date Kingslim APP on your phone. ② Make sure you have connected the camera Wifi successfully on your phone’s Wifi...
- Page 37 In the unlikely event that we can’t help, we’re always happy to provide a full, and hassle-free refund under the warranty. We sincerely hope our customers are happy and proud to use KINGSLIM dash camera! There is no perfect product, however, we will do our best. For more details, please contact us by email.
-
Page 38: Contact Us
Contact Us For any inquiries about KINGSLIM products, please feel free to contact us. We will respond within 24 hours. ��...
