- Page 1 D1 PRO D A S H C A M D1 PRO V2.1...
- Page 2 User Agreement By purchasing Kingslim dash cams, you agree to Kingslim's terms including pre-cautions, user warnings, and conditions of the warranty. If for any reason you do not agree to any of the terms mentioned in this manual, then you may return the product in its original packaging, and unused within its return window for a full refund.
- Page 3 Warnings Failure to comply with safety warnings and regulations may result in serious injury or death. Please do not place the camera on top of the instrument panel or in front of the airbag in case it falls. Please do not mount the camera in any places on the windshield that may loosen your camera or distract you while driving.
-
Page 4: Table Of Contents
Start Recording -------------------------------------------------------------------------------- 19 Playback Videos ------------------------------------------------------------------------------- 22 1. Playback on the dash cam ---------------------------------------------------------------- 22 2. Playback on a computer------------------------------------------------------------------- 23 3. Playback on the Kingslim APP------------------------------------------------------------ 23 Camera Settings ------------------------------------------------------------------------------- 24 1. Video Settings -------------------------------------------------------------------------------- 24 2. System Settings ------------------------------------------------------------------------------ 26 Use the Kingslim APP ------------------------------------------------------------------------ 29 1. -
Page 5: Camera Specifications
Camera specifications LCD touch screen 2-inch IPS LCD screen Video resolution 4K, 4K+1080P, 2K+1080P Lens aperture F1/8 External GPS module Wifi Built-in Video format Memory card Class 10 U3 or higher, capacity up to 128GB G-sensor Built-in 3-axis gyroscope Light source frequency 60Hz, 50Hz Loop recording Seamless loop recording... -
Page 6: Getting Started
Getting Started Please read and understand warnings & safety instructions before operating. 1. Inserting Memory Card Before using this camera, please insert a Class 10 U3 or higher memory card of well-known brands at a maximum of 128GB. Please format the memory card before using it. -
Page 7: Recording
4. Recording KINGSLIM 4K D1 Pro dash cam is programmed to turn on and start recording automatically when it receives power. It will also start recording after you finish changing settings. To pause recording, please press . When unplugged, this dash cam will also automatically stop recording, safely save the last video, and shut down within 5 seconds. -
Page 8: What's In The Box
What’s in the box D1 PRO D1 Pro Dash Cam Car Charger with External GPS Suction Cup Mount Electrostatic Sticker Car Crowbar Cable Clip Quick Start Guide ��... -
Page 9: Camera Overview
Camera Overview Mini USB Power Port Bracket Slot Power Button Microphone Memory Card Slot D1 PRO Front Camera IR LED & Indicator Light Speaker Inside Camera Screen Settings Button Wifi Button Reset Hole ��... -
Page 10: Icon Introduction
Icon Introduction Video Time Start Recording Parking Monitor Date Microphone Indicator Time Power Status Lock Video Recording Resolution Audio Recording (Mute/Unmute) Setup / Wifi Snapshot Playback Stop Recording Switch View Modes ��... - Page 11 Video Settings Backward System Settings Forward Backward Confirm Down ��...
-
Page 12: Led Indicators
LED Indicators Blue light staying on Battery fully charged+not recording Blue light flashing Battery fully charged+ recording Red and purple lights Charging+recording flashing alternatively Purple light staying on Charging ��... -
Page 13: Installation
A Samsung / Sandisk / Kingston Class 10 U3 or high memory card is highly recommended for the D1 Pro dash cam. This dash cam supports a memory card of up to128GB. Please format your card on your computer first and then in the camera settings before using it for better compatibility. - Page 14 (2) Format the memory card Please format the memory card each time you insert it into the camera. If you have not formatted the memory card, you will be prompted by a message that says "Insert Memory Card". ① Please press the Setup button, choose , then press the OK button to enter the system settings page.
- Page 15 ③ On this screen, press the OK button to enter the formatting page, choose “OK”, and then press the OK button to complete formatting. The system will exit automatically. All data will be deleted Cancel Kind reminder: All data will be deleted after formatting. Be sure to back up your important files before formatting.
-
Page 16: Install The Dash Cam On The Windshield
Clean the area thoroughly with a microfiber cloth to remove any dust, dirt, or oil that could affect the suction cup mount's grip. ③ Attach the suction cup mount Attach the suction cup mount onto the dash cam by aligning the notches or grooves. D1 PRO D1 PRO ��... - Page 17 D1 PRO D1 PRO ④ Place the dash cam Remove the film of the GPS electrostatic sticker and apply it to the windshield; peel off the other film of the sticker and attach the dash cam onto the sticker, pressing the bracket firmly against the surface until it sticks securely.
-
Page 18: Charging
(2) Turn your camera ON/OFF Auto Power ON: KINGSLIM D1 Pro dash cam is designed to turn ON automatically when it receives power, i.e. when the car engine is started. Auto Power OFF: The camera is also pre-configured to turn OFF automatically within a few seconds when the power gets disconnected, i.e. - Page 19 (3) Install the hardwire kit Installing the hardwire kit helps prevent the camera battery from draining the car battery thanks to its smart low voltage protection system. Above all, installing the hardwire kit allows you to connect the camera directly to the vehicle's electrical system, providing a continuous and stable power supply.
-
Page 20: Start Recording
Start Recording 1. 4K Single Recording (Front Camera). ① After turning on the camera, press the button to stop recording. ② Press the Setup button to enter the camera settings page and choose then press the OK button to enter the video settings page. Press the Down button to choose “Resolution”, and press the OK button to choose “4K”, and then press the OK button to save the change and exit. - Page 21 ③ Press the Back button twice to go back to the main interface, and press to start capturing. The front camera will record 4K videos. One-press quick recording: Press to switch to single (front) recording, and press to start capturing. The front camera will record 4K videos. 2.
- Page 22 2K+1080P 4K+1080P ③ Press the Back button twice to go back to the main screen, and press to start capturing. The front and cabin cams will record 2K/4K and 1080P videos respectively. One-press quick recording: Press the button to switch to dual (front and cabin) recording, and press to start capturing.
-
Page 23: Playback Videos
Playback Videos 1. Playback on the dash cam You can choose to play back normal videos, locked videos, parking monitor videos, and photos on the dash cam. After turning on the camera, press the button to stop recording, and press to enter the playback screen, then press the Down button to playback files stored in the memory card. -
Page 24: Playback On A Computer
GPS data won't show if you playback the video on your own player. 3. Playback on the Kingslim APP You can also playback videos on the Kingslim APP after connecting your dash cam to the APP. For more details, please refer to Download the Kingslim APP→Playback videos on the APP. -
Page 25: Camera Settings
Camera Settings After turning on the camera, press the button to stop recording. 1. Video Settings Press the Setup button to enter the camera settings page, choose , then press the OK button to enter the video settings page. (1) Resolution 4K, 2K+1080P, 4K+1080P (The default setting is 4K+1080P) Press the Down button to choose "Resolution", and press the OK button to enter the setting to choose from 4K, 2K+1080P, and 4K+1080P, then press the OK... - Page 26 (4) WDR (Wide Dynamic Range) Off, On (The default setting is Off) Turn WDR on or off. WDR is ideal for use in high-contrast scenes, allowing for more details in images. (5) Record Audio Off, On (The default setting is On) You can choose to record videos with or without audio.
-
Page 27: System Settings
2. System Settings Press the Setup button to enter the camera settings page, choose then press the OK button to enter the system settings page. (1) Screen Saver Off, 30 Sec, 1 Minute, 2 Minutes (The default setting is Off) Press the Down button to choose “Screen Saver”, then press the OK button to set the screensaver time. - Page 28 (6) Beep Sound Off, On (The default setting is on) Turn beep sounds on or off. (7) Language English, 简体中文, 繁体中文, Français, Español, Deutsc, Italiano, 日本語, 한국어 (The default setting is English) Set the system language for your dash cam. (8) Parking Monitor Off, On (The default setting is Off) When the car engine is off, the dash cam will enter parking monitor mode...
- Page 29 (12) Speed Unit KM/H, MP/H (The default setting is MP/H) You can press the Down button to choose "Speed Unit", and press the OK button to choose from KM/H and MP/H, then press the OK button to save the change and exit.
-
Page 30: Use The Kingslim App
Use the Kingslim APP Once you have successfully connected your dash cam to the Kingslim APP via the camera Wifi, you will be able to access the camera, view and download videos via the APP. You can also control the camera to capture or change the camera settings using the phone APP. - Page 31 4G signal of your phone is blocked, but you can ignore it and continue the app connection. (4) Open the Kingslim APP, tap the New Account icon, enter your email and get a verification code for login. Warm tip:...
-
Page 32: Playback Videos On The App
3. Playback videos on the APP (1) Tap the “Video set” icon to enter the video menu. (2) Tap the video you want to watch for playback. NVT_ **** Note: The Kingslim APP works with KINGSLIM dash cams only. ��... -
Page 33: Download Videos From The App
4. Download videos from the APP (1) Tap the “Video set” icon to enter the video menu. NVT_ **** (2) Tap the “Select” icon in the upper right corner, and choose the video you want to download. ��... - Page 34 (3) Tap the Download icon in the bottom left corner to download the video. (4) Waiting for the completion of the download progress, the video will be downloaded to your phone's album. ��...
-
Page 35: General Faq
General FAQ Warm Tips: For any product issues, please feel free to contact us anytime for technical support. 1. What to do if the dash cam does not turn on anymore? ➀ Check if the indicator light on the car charger turns on when your dash cam is plugged in. - Page 36 4. What to do if the KINGSLIM APP can't connect to your dash cam? ➀ Make sure you have installed the up-to-date Kingslim APP on your phone. ➁ Make sure the you have connected the camera Wifi successfully on your phone’s Wifi...
- Page 37 In the unlikely event that we can’t help, we’re always happy to provide a full, and hassle-free refund under the warranty. We sincerely hope our customers are happy and proud to use KINGSLIM dash camera! There is no perfect product, however, we will do our best. For more details, please contact us by email.
-
Page 38: Contact Us
Contact Us For any inquiries about KINGSLIM products, please feel free to contact us. We will respond within 24 hours. ��...
