Replacement Parts
Replacement Parts
Servicing the IO-R-34 may call for replacement parts. There are two categories of parts:

Standard Replacement Parts

New Replacement Units
Standard Replacement Parts
Standard replacement parts are listed in
replacement parts cannot be returned for credit and should be disposed of in an appropriate manner.
Table 2
Parts Listing for IO-R-34
Part Number
Item
32327282-001 Replacement Unit IO-R-34 option module, model #14022
10600
Connector plug
10599
Connector plug
10598
Connector plug
32330828
Connector plug
Accessory Kit,
32327803
IO-R-34
New Replacement Units
To replace a faulty unit, order and install a new IO-R-34 accessory module. If the faulty IO-R-34 is still in warranty,
you can receive credit by returning it. Be sure to contact the vendor for a return material authorization (RMA) number
before shipping an item for return credit. See
Before ordering a new IO-R-34, it is strongly recommended that you contact your normal technical support
Note
resource to eliminate the possibility of a software issue or mis-configuration problem.
Replacing an IO-R-34
Before handling circuit boards, discharge any accumulated static by touching the nearby earth
Caution
grounding point. For details, see the
To replace the IO-R-34 module in the field, proceed as follows:
Procedure 2
Replacing an IO-R-34 accessory module.
Using the appropriate EC-Net software tool, back up the EC-BOS's configuration to your PC.
Step 1
Remove power to the IO-R-34. The unit should power down automatically.
Step 2
If any I/O points have voltage, turn the devices off or disconnect power to them.
Note
Note positions of all I/O wiring going to the IO-R-34. If necessary, label connectors to avoid mis-connection
Step 3
later (after module is replaced). The software that runs on the controller expects the terminal positions to
be the same in the replacement IO-R-34, in order to collect data from or to control the attached devices.
Unplug all connectors from the IO-R-34, including all I/O connectors, power, and earth ground wire.
Step 4
Remove any screws or DIN rail clips securing the module, removing it from its mounting. See
Step 5
page 6 for details on removal from (and mounting onto) DIN rail.
16
Table 2
and can be ordered from stock without restriction. Standard
15 position screw terminal, 180 deg.
12 position screw terminal, 180 deg.
2 position screw terminal, 180 deg.
5 position screw terminal, 180 deg.
– One (1) grounding wire, with quick-disconnect 0.187" female connector.
– Sixteen (16) 499-ohm resistors , +/-1%, 0.6W.
"Returning a Defective Unit,"
"Static Discharge Precautions"
August 2, 2017
Description
page 17, for details.
section on page 4.
Remote IO-R-34 Module Mounting and Wiring Guide
Replacement Parts
Figure 1
on
