DPX-XT
Advanced XT/XT-2P/XT-4P Extender
USER MANUAL
DPX-XT
Single Head DisplayPort, USB 2.0 and Audio KVM CAT5/6 Extender
DPX-XT-2P
Dual Head DisplayPort, USB 2.0 and Audio KVM CAT5/6 Extender
DPX-XT-4P
Quad Head DisplayPort, USB 2.0 and Audio KVM CAT5/6 Extender
1-800-284-2131
www.smartavi.com
Advanced XT/XT-2P/XT-4P Extender
series
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SMART-AVI DPX-XT Series
Summary of Contents for SMART-AVI DPX-XT Series
- Page 1 DPX-XT series Advanced XT/XT-2P/XT-4P Extender USER MANUAL DPX-XT Single Head DisplayPort, USB 2.0 and Audio KVM CAT5/6 Extender DPX-XT-2P Dual Head DisplayPort, USB 2.0 and Audio KVM CAT5/6 Extender DPX-XT-4P Quad Head DisplayPort, USB 2.0 and Audio KVM CAT5/6 Extender 1-800-284-2131 www.smartavi.com Advanced XT/XT-2P/XT-4P Extender...
-
Page 2: Table Of Contents
Table of content TECHNICAL SPECIFICATIONS_____________________________________________________________ 3 WHAT’S IN THE BOX?_____________________________________________________________________ 4 FRONT AND REAR________________________________________________________________________ 4 INSTALLATION____________________________________________________________________________ 5-8 LED’s BEHAVIOR__________________________________________________________________________ 11 SYSTEM OPERATION______________________________________________________________________ 12 TROUBLESHOOTING______________________________________________________________________ 12 TECHNICAL SUPPORT_____________________________________________________________________ 12 LIMITED WARRANTY STATEMENT________________________________________________________ 13 Advanced XT/XT-2P/XT-4P Extender... -
Page 3: Technical Specifications
Technical Specifications VIDEO Format DisplayPort 1.1 and 1.2 Video Resolution 3840 x 2160 @ 30 Hz Video Bandwidth Single-link 340 MHz (10.2 Gbps) DPX-XT (1) DisplayPort Input Interface (TX) DPX-XT-2P (2) DisplayPort DPX-XT-4P (4) DisplayPort DPX-XT (1) DisplayPort Output Interface (RX) DPX-XT-2P (2) DisplayPort DPX-XT-4P... -
Page 4: What's In The Box
What’s in the box? DPX-XT Unit Single/Dual/Quad Head DisplayPort, USB 2.0, Audio, CAT5/5e/6 Extender. PS5VD3A-WMT 5V DC, 3A (minimum) power adapter with center-pin positive polarity. User Manual DPX-xT Transmitter rear DPX-XT transmitter front DPX-XT receiver rear DPX-XT receiver front Advanced XT/XT-2P/XT-4P Extender... -
Page 5: Installation
installation 1. Ensure that power is turned off or disconnected from the unit and the computers. 2. Use a DisplayPort cable to connect the DP output port from each computer to the corresponding DP IN ports of the unit. 3. Use a USB cable (Type-A to Type-B) to connect a USB port on each computer to the respective USB ports of the unit. - Page 6 Application diagram DPX-XT-2P The DPX-XT-2P is Dual Head DisplayPort 4K/30Hz, USB 2.0, USB 1.1 keyboard-mouse and stereo audio extender, sending signals up to 330 ft (100 m) away over two conventional and inexpensive CAT5/5e/6 cables. Part No. Description Dual Head DisplayPort, USB 2.0, Audio, CAT5/5e/6 Extender. DPX-XT-2P-S Includes: [DPX-XT-2P-TX-S, DPX-XT-2P-RX-S, 2x (PS5VD3A-WMT)] Dual Head DisplayPort, USB 2.0, Audio, CAT5/5e/6 Transmitter.
- Page 7 Application diagram DPX-XT-4P The DPX-XT-4P is Quad Head DisplayPort 4K/30Hz, USB 2.0, USB 1.1 keyboard-mouse and stereo audio extender, sending signals up to 330 ft (100 m) away over four conventional and inexpensive CAT5/5e/6 cables. Part No. Description Quad Head DisplayPort, USB 2.0, Audio, CAT5/5e/6 Extender. DPX-XT-4P-S Includes: [DPX-XT-4P-TX-S, DPX-XT-4P-RX-S, 2x (PS5VD3A-WMT)] Quad Head DisplayPort, USB 2.0, Audio, CAT5/5e/6 Transmitter.
- Page 8 Led control NAME DESCRIPTION Solid red LED when power is connected Link Solid green LED when cat5 is connected Blinking green LED when transferring information between unit and computer Advanced XT/XT-2P/XT-4P Extender...
-
Page 9: Troubleshooting
Troubleshooting No Power Make sure that the power adapter is securely connected to the power connector of the unit. Check the output voltage of the power supply and make sure that the voltage value is around 12VDC. Replace the power supply. No Video ... -
Page 10: Limited Warranty Statement
Limited warranty statement A. Extent of limited warranty SmartAVI, Inc. warrants to the end-user customers that the SmartAVI product specified above will be free from defects in materials and workmanship for the duration of 1 year, which duration begins on the date of purchase by the customer. - Page 11 NOTICE The information contained in this document is subject to change without notice. SmartAVI makes no warranty of any kind with regard to this material, including but not limited to, implied warranties of merchantability and fitness for particular purpose. SmartAVI will not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance or use of this material.
