BT5890-010
BT5890-075
BT5890-150
REGISTERED DESIGN
Installation Safety Notes.....................................................................................................................2
BT5890-010 Installation Instructions.......................................................................................................4
BT5890-075 & BT5890-150 Installation Instructions...............................................................................5
Product Dimensions..........................................................................................................................10
B-Tech Contact Details.....................................................................................................................12
13mm (1/2") spanner
or socket
Flathead
Drill
screwdriver
www.btechavmounts.com
The System V ™ range is available in
package or component form.
This installation guide demonstrates
how to install and use the System V ™
projector mounting range from
B-Tech.
10mm (7/16") masonry bit
or 6mm (1/4") wood bit
Saw
Pencil
(Optional)
Advertisement
Related Manuals for B-Tech SYSTEM V Series
Summary of Contents for B-Tech SYSTEM V Series
- Page 1 System V ™ projector mounting range from B-Tech. REGISTERED DESIGN Installation Safety Notes........................2 BT5890-010 Installation Instructions.......................4 BT5890-075 & BT5890-150 Installation Instructions................5 Product Dimensions..........................10 B-Tech Contact Details........................12 13mm (1/2") spanner 10mm (7/16") masonry bit Flathead Drill Pencil (Optional) or socket or 6mm (1/4") wood bit...
- Page 2 Do not attempt to install this product until all instructions and warnings have been read and properly understood. Please keep these instructions for future reference. B-Tech International Limited, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure to observe these safety instructions. In such cases, all guarantees will expire.
- Page 3 Spole nost B-Tech International Ltd. doporu uje provést instalaci tohoto produktu prost ednictvím odborného instalátora AV i jinak zp sobilé osoby. Spole nost B-Tech International Ltd, její distributo i a prodejci nenesou odpov dnost za škody nebo zran ní zp sobená nevhodnou instalací. Tento výrobek je nutno umístit do vhodné...
- Page 4 FOR BT5890-075 & BT5890-150 INSTALLATION INSTRUCTIONS GO TO PAGE 5 !"# #$# Fix the BT5820 ceiling plate to the ceiling. No. 10 CEILING PLUG ONLY USE CEILING PLUG WHEN FIXING TO CONCRETE CEILINGS BT5820 CEILING PLATE M8 WASHER M8 x 50mm COACH SCREW BT5820 TRIM...
- Page 5 !"# #& !"# $ # Fix the BT5820 ceiling plate to the ceiling. No. 10 CEILING PLUG ONLY USE CEILING PLUG WHEN FIXING TO CONCRETE CEILINGS BT5820 CEILING PLATE M8 WASHER M8 x 50mm COACH SCREW BT5820 TRIM OPTIONAL: Cut BT5835 pole to desired length. SUGGESTED CUTTING POINTS...
- Page 6 i. Fix one M8 x 15mm screw into the BT5835 pole as shown, leaving 6mm of thread showing. BT5835 35mm POLE IMPORTANT 0.2" M8 x 15mm SCREW ii. Attach the BT5835 pole to the BT5820 ceiling mount. BT5820 CEILING PLATE M8 x 50mm SCREW M5 x 10mm...
- Page 7 There are two methods of attaching the mount to the projector, depending on the projector fixing pattern. A. 75 x 75mm & 100 x 100mm (page 7) B. All other fixing patterns up to 493mm apart (page 8) Attach the carousel directly to the projector. M3 x 25mm M4 x 25mm M5 x 25mm...
- Page 8 i. Attach the legs to the carousel. M6 WASHER M6 x 8mm SCREW M6 x 8mm SCREW M6 WASHER MOUNTING SCREW MOUNTING SCREW LONG LEG SHORT LEG ii. Attach the legs to the projector. M3 x 25mm M5 x 25mm SCREW SCREW M4 x 25mm...
- Page 9 Hook the BT5880 onto the M8 Secure the BT5880 using the screw using the keyhole fixing. M8 screws provided. M8 WASHER M8 x 15mm M8 SPRING WASHER SCREW M8 x 15mm SCREW BT5835 35mm POLE BT5820 BT5880 CEILING MOUNT M8 SCREW M8 WASHER M8 SPRING WASHER M8 x 55mm SCREW...
- Page 10 MAXIMUM DISTANCE SUITABLE FOR MAXIMUM PRODUCT CEILING DROP BETWEEN ANY 2 TILT ROLL SWIVEL PROJECTORS LOAD FIXING POINTS WITH FIXINGS BT5890-010 190mm (7.5") M2.5, M3, M4, BT5890-075 895mm (35.2") M5 & M6 BT5890-150 1645mm (64.8") 493mm 19.4" BT5890-010 BT5890-075 BT5890-150 BT5820 BT5820 CEILING MOUNT...
- Page 11 BT5820 CEILING PLATE 20mm 0.8" 8.5mm 0.3" 42mm 1.7" 150mm 5.9" 120mm 4.7" BT5880 INTERFACE NO LEGS LONG LEGS 100mm 3.9" 143.5mm 5.6" SHORT LEGS 338mm FITS UP TO 13.3" 400 x 200mm 493mm PROJECTOR 19.4" 263.5mm FIXINGS 10.4"...
- Page 12 ©2011 B-Tech International Limited. All rights reserved. B-Tech Audio Video Mounts is a division of B-Tech International Limited. B-Tech, Better By Design and Mountlogic are registered trademarks of B-Tech International Limited. All other brands and product names are trademarks of their respective owners.
