BT7581
FLAT SCREEN CEILING MOUNT
FOR SMALL SCREENS
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Mount
PLEASE KEEP THIS FOR FUTURE REFERENCE
Installation Safety Notes.......................................................................................................................2
Parts List..............................................................................................................................................4
Installation Instructions.........................................................................................................................6
Product Dimensions............................................................................................................................11
B-Tech Contact Details.......................................................................................................................12
INSTALLATION TOOLS REQUIRED
Crosshead
screwdriver
B-TECH AUDIO VIDEO MOUNTS
FEATURES
● Designed for flat screen up to 23" (58cm) / 10kg (22lbs)
● Fits screens with VESA mounting patterns:
50 x 50mm, 75 x 75mm and 100 x 100mm
● Fixed ceiling drop of 205mm (8")
● Features +/- 90° tilt and 360° swivel
● Post installation screen levelling
● Cover plate included for smart installation
● Simple installation
● All mounting hardware included
CONTENTS
8mm (1/3") masonry bit
Drill
or 3mm (1/8") wood bit
www.btechavmounts.com
Pencil
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for B-Tech montlogic BT7581
Summary of Contents for B-Tech montlogic BT7581
-
Page 1: Table Of Contents
● Simple installation ● All mounting hardware included CONTENTS Installation Safety Notes........................2 Parts List..............................4 Installation Instructions.........................6 Product Dimensions..........................11 B-Tech Contact Details........................12 INSTALLATION TOOLS REQUIRED Crosshead 8mm (1/3") masonry bit Pencil Drill screwdriver or 3mm (1/8") wood bit B-TECH AUDIO VIDEO MOUNTS www.btechavmounts.com... -
Page 2: Installation Safety Notes
Do not attempt to install this product until all instructions and warnings have been read and properly understood. Please keep these instructions for future reference. B-Tech International Limited, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure to observe these safety instructions. - Page 3 Niniejszy produkt musi być zamontowany na odpowiedniej powierzchni, a podczas użytkowania nie wolno przekraczać podanego maksymalnego obciążenia. A B-Tech International Ltd. recomenda que a instalação deste produto seja efectuada por um instalador de AV profissional ou outra pessoa devidamente habilitada. A B-Tech International Ltd. e os seus distribuidores e concessionários não são responsáveis por danos ou lesões causados por uma instalação incorrecta.
-
Page 4: Parts List
BT7581 PARTS LIST Supplied pre-assembled Suitable for loads up to 10kg (22lbs) - Page 5 FLAT SCREEN INTERFACE KIT PART NAME (FOR ATTACHING MOUNT TO CEILING PLATE BACK OF FLAT SCREEN) COVER PLATE M8 NUT M8 SPRING WASHER SPACER LONG EXTENSION ROD BALL JOINT M6 x 6mm GRUB SCREW M6 x 10mm GRUB SCREW M8 FEMALE ADAPTOR INTERFACE PLATE M8 x 20mm HEX SCREW SECURITY CABLE...
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Remove the cover plates, then fix the ceiling plate to the ceiling. ONLY USE PART A3 WHEN FIXING TO CONCRETE CEILINGS... - Page 7 Re-attach the cover plates.
- Page 8 Attach interface plate to the flat screen using 3 interface screws (parts A). FLAT SCREEN Connect the adaptor to the ball joint and secure using parts 9. FLAT SCREEN...
- Page 9 Place cable loop over vacant screw hole, secure in place using parts B and C. FLAT SCREEN FLAT SCREEN...
- Page 10 Adjusting the screen. 90° FLAT SCREEN 360°...
-
Page 11: Product Dimensions
3.9" 88mm 75mm 3.5" 3" 14.5mm 50mm 0.6" 2" 45mm 1.8" 59mm 2.3" 74mm 115mm 2.9" 4.5" THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT. -
Page 12: B-Tech Contact Details
©2010 Bennett Technologies Limited. All rights reserved. B-Tech Audio Video Mounts is a division of Bennett Technologies Limited. B-Tech, Better By Design & Mountlogic are registered trademarks of Bennett Technologies Limited. All other brands and product names are trademarks of their respective owners.
