Tall Pedestal Kit for FK11/FB11 and FK12/FB12
Installation Guide
2.2 Overview of Pedestal Installation
1
2
3
4
5
6
7
Illustration 1: Pedestal Kit Overview
1
Locking bracket
2
M10 nylon-insert lock nut
3
M10x22 screws
4
M8 nut
5
Front top bracket
Danfoss A/S © 2022.03
6
M5x14 countersunk screws
7
Front panel
8
Pedestal
9
Pedestal cutout
10
Front bottom bracket
AN361529835714en-000101 / 136R0257 | 3
Installation
8
9
10
