4.3. Data displayed on the LCD
Page
1 Date
2 Time
3 Total active energy consumption
4 T1 tariff – active energy consumption
5 T2 tariff – active energy consumption
6 T3 tariff – active energy consumption
7
T4 tariff – active energy consumption
8 Total reactive energy consumption
9
T1 tariff – reactive energy consumption
10 T2 tariff – reactive energy consumption
11
T3 tariff – reactive energy consumption
12 T4 tariff – reactive energy consumption
13
L1 – Phase voltage
14 L2 – Phase voltage
15 L3 Phase voltage
16 L1 – Phase current
17 L2 – Phase current
18 L3 – Phase current
19 Total active power
20 L1 – active power
21 L2 – active power
22
L3 – active power
23 Total apparent power
24
L1 – apparent power
25 L2 – apparent power
26
L3 – apparent power
27 Total power factor
28
L1 – power factor
29 L2 – power factor
30 L3 – power factor
Warning!
The meter records absolute values of power and power factor.
LE-03MW CT – user manual
Parameter Unit Symbol
kWh
kWh T01
kWh T02
kWh T03
kWh T04
kVarh
kVarh T11
kVarh T12
kVarh T13
kVarh T14
V L1
V L2
V L3
A L1
A L2
A L3
kW
kW L1
kW L2
kW L3
kVA
kVA L1
kVA L2
kVA L3
L1
L2
L3
6
Format
XX-XX-XX
XX-XX-XX
6+2 000000.00
6+2 000000.00
6+2 000000.00
6+2 000000.00
6+2 000000.00
6+2 000000.00
6+2 000000.00
6+2 000000.00
6+2 000000.00
6+2 000000.00
3+1 000.0
3+1 000.0
3+1 000.0
4+2 0000.00
4+2 0000.00
4+2 0000.00
5+3 00000.000
5+3 00000.000
5+3 00000.000
5+3 00000.000
5+3 00000.000
5+3 00000.000
5+3 00000.000
5+3 00000.000
1+2 0.00
1+2 0.00
1+2 0.00
1+2 0.00
