- Page 1 NSTRUCTION MANUAL AIR 54 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled.
-
Page 4: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 60MIN. ASSEMBLY HARDWARE M4.0x60 mm SCREW M6.0x65 mm BOLT 26PCS+1 spare 12PCS+1 spare M4.0x45 mm SCREW M3.5x35 mm SCREW 34PCS+1 spare 12PCS+1 spare M3.5x30 mm SCREW M3.0x25 mm SCREW 2PCS+1 spare 12PCS+1 spare... - Page 5 Wooden house Back Left Right Front...
- Page 6 PARTS CARTON 1/3 Upper wire panel- left Supporting bars of small platform Supporting bars 2PCS 4PCS Lower wire panel- left Front wire panel- upper Front wire panel- middle Front wire panel- down Shelf panel Roof of wooden house...
- Page 7 PARTS Hardware bag Wire Roof 2PCS...
- Page 8 PARTS CARTON 2/3 Wooden house panel- upper & Wooden house panel- upper & Wooden house panel- back & left right upper Wooden house panel- back & Wooden house panel- back & Divider - upper middle down Upper wire panel- right Divider- middle Lower wire panel- right...
- Page 9 PARTS Wire panel...
- Page 10 PARTS CARTON 3/3 Wooden house panel- down left Wooden house panel- down right Layer 3PCS Shelf panel- down area Layer Layer 2PCS Platform layer Wire panel Wire panel...
- Page 11 PARTS Wire panel...
-
Page 12: Product Assembly
PRODUCT ASSEMBLY Connect the wooden house panel, screw the left & right panel A1, A2, B, B1 to the back panel C, D, E by 12XP3. Attach the dividers Part F & G to the left and right side of wooden house by 10XP3. - Page 13 PRODUCT ASSEMBLY Put layer Part H1 in lower position of wooden house, screw layer Part I in lower position of wooden house by 2XP6. Put layers Part H1 and I in middle position of wooden house.
- Page 14 PRODUCT ASSEMBLY Put layers Part H1 and H2 in upper position of wooden house. Attach the supporting bars Part K by 4XP1.
- Page 15 PRODUCT ASSEMBLY Screw the platform layer Part J to supporting bars by 4XP5. Connect the wire panels, screw Part O to Part M and Part N to Part P by 2XP2 each side. NOTICE: Pre-drill holes to be bolted by supporting bars in step 10.
- Page 16 PRODUCT ASSEMBLY Attach the step 08 to wooden house by 4XP2 each side. Attach 2 supporting bars Part L by 4XP1 each side.
- Page 17 PRODUCT ASSEMBLY Screw shelf panel Part V by 4XP5. Connect 2 side wire panels, screw Part Q to Part R and Part Q1 to Part R1 by 2XP2 each side.
- Page 18 PRODUCT ASSEMBLY Attach the step 12 to step 11 by 8XP2. Connect the front wire panels, screw Part S, T, U by 2XP2,screw the supporting bars ① Part L in down area by 4XP1. ② Screw the shelf panel Part W in down area by 4XP5.
- Page 19 PRODUCT ASSEMBLY Screw the front wire panels by 12XP3.
- Page 20 PRODUCT ASSEMBLY Screw the wire roof Part Y by 8XP4.
- Page 21 PRODUCT ASSEMBLY Screw roof Part X to the wooden house by 4XP4. Finish...
- Page 22 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this...
