INSTRUCTION
MANUAL
AIR21
WARNING
Maunfacturer and seller expressly disclaim any and all liability for personal injury,property
damage or loss,whether direct,indirect,or incidental,resulting from the incorrect
attachment,improper use,inadequate miantenance,or neglect of this product.
www.aivituvin.com
Advertisement
Table of Contents
Related Manuals for aivituvin AIR21
Summary of Contents for aivituvin AIR21
- Page 1 INSTRUCTION MANUAL AIR21 WARNING Maunfacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product. www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
- Page 3 TOOLS REQUIRED PARTS Front panel Back panel Left panel PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 30MIN. ASSEMBLY HARDWARE M3.5x50mm SCREW M3.5x40mm SCREW 4PCS+1 spare 11PCS+1 spare Divider Right panel Wooden roof M3.0x16mm SCREW Latch 20PCS+1 spare 2PCS M4.0x55mm SCREW 2PCS Wire roof Tray...
- Page 4 PARTS PRODUCT ASSEMBLY Lamp Frame Support Bar Lengthwise Lamp Frame Support Attach C , D , E to A by 5xP2 screws. ① Attach the back B to C , D and E by 5xP2 screws. ②Ensure all corners line up before screwing together.
- Page 5 PRODUCT ASSEMBLY PRODUCT ASSEMBLY ① Put in the “H” from the bottom. Complete the roof by screwing the latch P4 by 8xP3 screws. ②Screw “H” to the house from the bottom up by 4xP1 screws. ① Screw F, G to the house at the hinges by 8xP3 screws. Screw I to the K by 1xP2 screw.
- Page 6 PRODUCT ASSEMBLY PRODUCT ASSEMBLY ① Pls ignore the following for only one tortoise house owner! Screw J by 2xP7 screws. ② The below steps are the assembly for the 2nd tortoise house if you buying 2 houses. Take out the side panel Part C from the TWO tortoise house separately. Attached Lamp Frame Support to the house by 2xP6 screws.
- Page 7 PRODUCT ASSEMBLY PRODUCT ASSEMBLY Screw the connect pieces P5 by 4xP3 screws. Repeat on the other side.
- Page 8 Once the items are received, opened, and deemed to be faulty or other problems. Pls contact us at service@aivituvin.com for the solution. We will feedback to you within 24 hours. If you are happy with the shopping ,welcome to share photos and thoughts with others .
