- Page 1 INSTRUCTION MANUAL AIR 15 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 4: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x35mm SCREW M4.0x45mm SCREW 8PCS+1spare 18PCS+1spare M3.0x16mm SCREW M3.5x25mm SCREW 20PCS+1spare 2PCS+1spare Chewing toy M3.0x10mm SCREW 2PCS+1spare... - Page 6 PARTS Back panel - Up Front panel - Down Front panel - Upper Back panel - Down Left panel Right panel Middle plastic tray Divider Bottom wire netting 2PCS...
- Page 7 PARTS Asphalt roof x2 Bottom plastic tray Ramp 2PCS Roof cap Casters without brake Brake casters 2PCS 2PCS Folding metal feeder Ramp Supporting board...
-
Page 8: Product Assembly
PRODUCT ASSEMBLY Attach the back panels up Part C, down Part D to the left side panel Part E and right side Part F by 4xP1 screws each side. Attach the down panel Part B by 2xP1 screws each side. - Page 9 PRODUCT ASSEMBLY Put inside the wire bottom floor Part I to be UPWARDS in order to seperate the urine & poop. Screw the ramp supporting board Part Q to the Part D by 2xP2 screws. ( Notice: The ramp supporting board Part Q is only assembled if you don't need the bottom wire netting)
- Page 10 PRODUCT ASSEMBLY Screw the ramp Part J to the bar of Part E by 2xP4 screws. Attach Part A by 2xP1 screws each side.
- Page 11 PRODUCT ASSEMBLY Slide in the middle tray Part G and bottom tray Part K. Screw the metal feeder Part P to the Part F by 2xP5 screws.
- Page 12 PRODUCT ASSEMBLY Slide in the divider Part H. Screw two casters without brake Part N to the front of hutch legs by P3x8 screws.
- Page 13 PRODUCT ASSEMBLY Screw two brake casters Part O to the back of hutch legs by P3X8 screws. ① Screw the 2 roof Part L to the top by 8xP2. ② Notice to level up the roof.
- Page 14 PRODUCT ASSEMBLY Screw the roof cap Part M by 4xP3 screws. LOCKED OPEN Finish...
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
