  • Page 1 INSTRUCTION MANUAL AIR 14 www.aivituvin.com...
  • Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.

  • Page 3: Tools Required

    TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 30MIN. ASSEMBLY HARDWARE M3.5x45mm SCREW M5.0x45mm BOLT 4PCS+1spare 2PCS+1spare M3.5x25mm SCREW M3.5x40mm SCREW 12PCS+1spare 12PCS+1spare M3.0x16mm SCREW Roof hinge 12PCS+1spare...
  • Page 4 PARTS Left side panel Front panel Back panel The Bottom Floor Right side panel The Middle Floor 2PCS Roof Ramp Roof Overhang...
  • Page 5 PARTS The Bottom Step Step supporting bar The middle step 4PCS Brake casters Normal casters 2PCS 2PCS...

  • Page 6: Product Assembly

    PRODUCT ASSEMBLY Screw Part H from the inner by 2xP2 screws. ① Attach Part L into the panel D from the inner by 1xP4 on the upper position and 1xP1 on the down position. ② Repeat the same ways for 4 bars. X 1 X 4 X 1 X 4...
  • Page 7 PRODUCT ASSEMBLY Attach Part A, Part C, Part D, Part B by 12xP3 screws. Put 2 pieces of bottom floor Part F into the house.
  • Page 8 PRODUCT ASSEMBLY ① Attach the ramp Part G to the middle floor Part E by 2xP5 screws. ② And then put into the house. Screw Part K and Part J to Part L by 8xP4 screws.
  • Page 9 PRODUCT ASSEMBLY ① Attach the roof Part I to the house by 6xP5 screws. ② Notive to level up the hinge. ③ Screw the normal casters 2xN to the back legs of house. ① Attach the roof hinge P6 to the roof panel and left side panel by 4xP5 screws.

  • Page 10: Help Center

    Once the items are received, opened, and deemed to be faulty or other problems. Pls contact us at service@aivituvin.com for the solution. We will feedback to you within 24 hours. If you are happy with the shopping ,welcome to share photos and thoughts with others .
  • Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
