- Page 1 INSTRUCTION MANUAL AIR14 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 30MIN. ASSEMBLY HARDWERE M3.5x45mm SCREW M4.0x40mm SCREW 12PCS+ + 1 spare 4PCS+1 spare M3.5x25mm SCREW M3.5x35mm SCREW 4PCS ++ 1 spare 4PCS ++ 1 spare Plastic Feets 4PCS... - Page 4 PARTS PVC curtain Front panel Roof Overhang Upper panel- Right side 2PCS 1 PC 2PCS Layer panel- Upper Left panel Back panel Down panel- Right side 1 PC Layer panel- Down Roof...
-
Page 5: Product Assembly
PRODUCT ASSEMBLY ① Screw the curtain Part A to the INSIDE of Part B by 2xP4. ② Screw Part C to the INSIDE of Part B by 2xP1. ① Screw the curtain Part A to the INSIDE of Part D by 2xP4. ② ... - Page 6 PRODUCT ASSEMBLY Screw Part B, F, G and the right panel by 6xP2 on each side. Slide in the two layer panels.
- Page 7 PRODUCT ASSEMBLY Attach the roof Part J by 3xP4. Attach 4pcs of P4 to the feet of the cat house.
- Page 8 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
