- Page 1 INSTRUCTION MANUAL AIR 22 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x60mm SCREW M4.0x45mm SCREW 6PCS+1spare 8PCS+1spare M3.0x34mm SCREW M3.5x40mm SCREW 33PCS+1spare 24PCS+1spare M3.5x45mm SCREW M3.0x16mm SCREW 12PCS+1spare 4PCS+1spare Connect piece Eye hook 3PCS 4PCS... - Page 4 HARDWARE Hook 2PCS...
- Page 5 PARTS Back panel - Upper Front panel - Down Front panel - Upper Back panel - Down Left side panel - Upper Left side panel - Down Right side panel - Upper Right side panel - Down Roof...
- Page 6 PARTS Shelf panel in down area Middle layer Bottom floor 2PCS Shelf panel in upper area Shelf bar in upper area Shelf bar in upper area Wood handle Shelf bar in down area Brake casters 2PCS 2PCS 2PCS...
- Page 7 PARTS Right part of small house Left part of small house Casters without brake 2PCS Back part of small house Roof of small house Roof connect slats This is only for 2 hutches owner.No usage for only one hutch owner.) PVC layer...
-
Page 8: Product Assembly
PRODUCT ASSEMBLY ① Fix the shelf to the panel, attached 2 pcs Part L to the Part C2 by 4xP1 screws. ② Attached shelf J2 & shelf J1 to the Part C1 by 4xP1 screws. ( Notice do not confuse with the J2, J1.) Screw the handle K to the front panels A1 &... - Page 9 PRODUCT ASSEMBLY ① Assemble the down half hutch. ② Attached the 4 sides A2, B2 , C2, D2 together by 8xP3 screws. Screw the 2 casters without brake M2 to the front corners by 3xP3 screws each. M2x2...
- Page 10 PRODUCT ASSEMBLY Screw the 2 brake casters Part M1 to the back corners by 3xP3 screws each. M1x2 ① Put the 2 pcs floor Part F into the down half hutch. ② Put the back PVC layers Part R above the wood floor for easier cleaning.
- Page 11 PRODUCT ASSEMBLY Attached the shelf panel Part H on the shelf in the down area by 4xP4 screws. Put the middle layer Part G on the top slat of the down hutch close to the front panel.
- Page 12 PRODUCT ASSEMBLY ① Assemble the upper half hutch. ② Attached the 4 sides A1, B1, C1, D1 together by 8xP3 screws. Connect the front of the up and down hutch by 3xP2 screws. (Notice there are screw holes to direct finding the right position)
- Page 13 PRODUCT ASSEMBLY Connect the back of the up and down hutch by 3xP2 screws. (Notice there are screw holes to direct finding the right position) ① Assemble the small house! ② Attach Part O to N1 & N2 by 4xP4 screws. ③ Screw the roof Part P by 4xP4 screws.
- Page 14 PRODUCT ASSEMBLY ① Screw the panel I to the small house by 4xP4 screws. ② Attached the panel I to the shelf by 2xP4 screws. Screw 1xP3 screws through the inner shelf from the bottom. ③ Notice there is a predrill hole for direction. ④ ...
- Page 15 PRODUCT ASSEMBLY ① Attached the roof Part E to the hutch by 4xP6 screws. ② Ensure top roof panels line up with each other. ① Insert the eye hook 4xP8 screws into the position as show on the picture. ② Insert the set of eye hook P9 beside the door. ③ Notice there are predrill holes to direct.
- Page 16 PRODUCT ASSEMBLY REMARK: The below 3 steps are for 2 hutches to combine together. If you do only buy one hutch, pls ignore the following. ① Take out the Part D1 in the left hutch and take out the Part C1 in the right hutch to combine together.
- Page 17 PRODUCT ASSEMBLY ① Screw the connect piece 3xP7 in the middle frame of the 2 hutches by 2xP5 screws each. Screw the 4 brake casters in the 4 sides corners. ② And another 4 casters without brake in the middle positions. ③...
- Page 18 PRODUCT ASSEMBLY Screw the connect piece 3xP7 in the middle frame of the back hutches by 2xP5 screws each. Screw the roof connect slats Part Q in the middle by 6xP4 screws. Finish...
- Page 20 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
