INSTRUCTION
MANUAL
AIR08-B
www.aivituvin.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the AIR08-B and is the answer not in the manual?

Questions and answers

Related Manuals for aivituvin AIR08-B

Summary of Contents for aivituvin AIR08-B

  • Page 1 INSTRUCTION MANUAL AIR08-B www.aivituvin.com...
  • Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.

  • Page 4: Tools Required

    TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x35mm SCREW M3.5x40mm SCREW 17PCS+1 spare 8PCS+1spare M3.0x16mm SCREW M3.5x25mm SCREW 2PCS+1spare 6PCS+1spare...
  • Page 5 PARTS Front panel Back panel Right side panel Floor-Upper Left side panel Floor-Bottom 2PCS Little Back fence Little Left side fence Ramp frame-Left...
  • Page 6 PARTS Ramp frame-Right Ramp steps 3PCS...

  • Page 7: Product Assembly

    PRODUCT ASSEMBLY Attach the panel Parts A, B, C & D by 4XP1srews. Put the 2 pieces bottom floor part E inside the house.
  • Page 8 PRODUCT ASSEMBLY Attach the upper floor parts F to the house by 4xP3 screws. Attach the little Back fence part G to the upper floor with 1xP5 by 2xP4 screws and 1xP2 screws.
  • Page 9 PRODUCT ASSEMBLY Attach Little Left side fence part H to the upper floor by 3xP2 screws as show on pictures. Attach the ramp. ①  Attach the part I ,J and 3 pieces of ramp steps part K by 12xP2 ②  screws.
  • Page 10 PRODUCT ASSEMBLY Attach the ramp to the house by 1xP2 & 2xP3 screws as show on pictures. Finish...
  • Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
