Summary of Contents for aivituvin AIR 21
- Page 1 INSTRUCTION MANUAL AIR 21 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
- Page 4 TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x40mm SCREW M3.5x50mm SCREW 10PCS+1 spare 4PCS+1 spare M3.0x16mm SCREW Latch 25PCS+1 spare 2PCS Plastic botton 2PCS Plastic pipe...
- Page 5 PARTS Left panel Back panel Front panel Divider Wooden roof Right panel Wire roof Metal lamp tube Tray...
- Page 6 PARTS Metal lamp tube Metal lamp tube...
-
Page 7: Product Assembly
PRODUCT ASSEMBLY Attach C , D , E to the front panel A by 5xP2 screws. ① Attach C , D , E to the back panel B by 5xP2 screws. ② Ensure all corners line up before screwing together. ③... - Page 8 PRODUCT ASSEMBLY ① Screw F, G to the house at the hinges by 8xP3 screws. Ensure F and G are line up before screwing. ② Complete the roof by screwing the latch P4 by 8xP3 screws.
- Page 9 PRODUCT ASSEMBLY Rota the metal lamp holder firstly. ① Screw it to the cage using the P6 by 2xP3 on the upper part ; then ② screw the lower part using P7 by 3xP3. Finish here for only buying one tortoise house...
- Page 10 PRODUCT ASSEMBLY ① Pls ignore the following for only one tortoise house owner! ② The below steps are the assembly for the 2nd tortoise house if you buying 2 houses. Take out the side panel Part C from one of the tortoise house. ①...
- Page 11 PRODUCT ASSEMBLY ① Screw the connect pieces P5 by 4xP3 screws. ② Repeat on the other side.
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
