I N S T A L L A T I O N G U I D E
for the
SB-N-ALT/10W3v3
SKU# 94447
2007+
Thank you for choosing a JL Audio Stealthbox for your automotive sound system. With proper installation, your new
®
vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox
installation professionals employed by your dealer have the necessary tools and experience to disassemble and
reassemble your vehicle properly. Also, keep in mind that your warranty coverage extends to 2 years if your system is
installed or approved by your authorized JL Audio dealer. If you prefer to perform your own installation, please read
this installation guide completely before beginning the process.
installed by your authorized JL Audio dealer. The
®
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
SB-N-ALT/10W3v3 INSTR SKU# 011287
INSTALLATION
D I F F I C U L T Y :
2
OUT
OF
ESTIMATED TIME:
2-3 HOURS
S T E P 1
Clean out the trunk so that you have a comfortable area to
work in.
S T E P 2
Position the 3" x 3" Wax Square as shown
S T E P 3
With the Stealthbox® laying on it's back, position and attach
the rear mounting bracket as shown with the foot roughly
parallel to the bottom of the enclosure.
(see DETAIL of hardware arrangement below)
Continued on Next Page
5
