JL Audio Stealthbox SB-N-FRNTCC/10W1v2 Installation Manual

I N S T A L L A T I O N G U I D E
for the
SB-N-FRNTCC/10W1v2 SB-N-FRNTCC/10W1v2
2005 - Up Nissan Frontier CrewCab Trucks 2005 - Up Nissan Frontier CrewCab Trucks
Thank you for choosing a JL Audio Stealthbox
installation, your new vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox
dealer. The installation professionals employed by your dealer have the necessary tools and experience
to disassemble and reassemble your vehicle properly. Also, keep in mind that your warranty coverage
extends to 1 year if your system is installed or approved by your authorized JL Audio dealer. If you
prefer to perform your own installation, please read this installation guide completely
before beginning the process.
® for your automotive sound system. With proper
® installed by your authorized JL Audio
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
SB-N-FRNTCC/10W1v2_INSTR_SKU#011229 SB-N-FRNTCC/10W1v2_INSTR_SKU#011229
INSTALLATION
D I F F I C U L T Y :
2
ESTIMATED TIME:
1 HOUR
S T E P 1
Remove both storage bins from under the rear seat.
If the truck is not equipped with the factory woofer, go to
STEP 4.
S T E P 2
Using a 10mm socket, remove the three mounting bolts that
secure the factory woofer enclosure to the truck's floor.
S T E P 3
Using a 10mm socket, remove the two mounting bolts that
secure this mounting bracket to the truck's floor.
Tuck the factory speaker wire under the carpet and out of
the mounting area of the Stealthbox®.
Continued on Next Page
