Wall installation

The telephone can also be installed on a wall.
You require two screws in order to fix the telephone on a wall.
Feed the guide tabs (1) on the wall−mounting bracket (2) in the slots (3)
on the rear side of the telephone. Slide the wall bracket (2) 10 mm
upwards until it audibly snaps into place.
Warning: Ensure that there are no cables or pipes etc. under the
surface of the wall where you want to drill the holes. Make sure that
the mounting height is less than 2 meters.
Drill two holes whose distance apart corresponds to the bracket to be
used, insert the screws and allow them to project 5 mm from the wall.
Position the telephone on the bracket, fit the screws in the slots and slide
the telephone downwards a little.
Turn the receiver hook (4) in the receiver cradle 180° so that the receiver
can be hooked in.
