FAST TRACK Mechanical Setup
These quick steps are for the experienced installer who needs a checklist to get a
standard installation up and running in the minimum of time.
Detailed installation features and functions are referred to later in this manual.
STEP
Gather Required Tools and Equipment
1
STEP
Heed Necessary Site Considerations
2
STEP
Check Cabling Requirements
3
STEP
Determine Gate Swing Angle
4
Determine Installation Type
STEP
• Inward Opening Installation
5
• Outward Opening Installation
STEP
Confirm that gate leaf meets allowable wind loading specifications
6
STEP
Mount the Gate and Wall Bracket(s)
7
STEP
Install Operator and Link to Gate
8
STEP
Mount Controller Enclosure
9
