3.7. Allowable Wind Load

Wind speeds for which operator will still operate the gate.
(V400 or V500 operators)
For a 25% covered gate: (Palisades, etc.) x 1.8 metre high
Value of
A or B
dimension
Up to
once
installed
1
100mm 94km/h
140mm 119km/h
180mm 138km/h
220mm 156km/h
260mm 171km/h
300mm 186km/h
340mm 199km/h
1. See Section 9/10 for installation details
2. An electric lock must be fitted
Wind speeds for which operator will still operate the gate.
(V400 or V500 operators)
For a 100% covered gate: (Fully-clad gates, etc.) x 1.8 metre high
Value of
A or B
dimension
Up to
once
installed
1
100mm 47km/h
140mm 59km/h
180mm 69km/h
220mm 78km/h
260mm 86km/h
300mm 93km/h
340mm 100km/h
1. See Section 9/10 for installation details
2. An electric lock must be fitted
Individual gate leaf lengths:
Up to
1.5m 2m
66km/h
85km/h
101km/h
114km/h
126km/h
137km/h
147km/h
Individual gate leaf lengths:
Up to
1.5m 2m
33km/h
43km/h
50km/h
57km/h
63km/h
63km/h
74km/h
Up to Up to
2.5m 3m
2
48km/h 44km/h
65km/h 57km/h
78km/h 67km/h
89km/h 76km/h
99km/h 84km/h
108km/h 91km/h
116km/h 98km/h
Up to Up to
2.5m 3m
2
24km/h 22km/h
32km/h 28km/h
39km/h 34km/h
44km/h 38km/h
49km/h 42km/h
54km/h 46km/h
58km/h 49km/h
page 14
Up to Up to
3.5m 4m
2 2
41km/h 37km/h
51km/h 46km/h
60km/h 53km/h
67km/h 60km/h
74km/h 65km/h
80km/h 71km/h
86km/h 76km/h
TABLE 6
Up to Up to
3.5m 4m
2 2
47km/h 19km/h
59km/h 23km/h
69km/h 27km/h
78km/h 30km/h
86km/h 33km/h
93km/h 35km/h
100km/h 38km/h
TABLE 7
