7 STATION JUMP N SWING SET
ASSEMBLY INSTRUCTION, CARE, MAINTENANCE AND USER'S GUIDE
- This product is intended for use by children from ages 3 to 8
- This unit is designed for use by up to 7 children at one time.
Maximum weight of each user is 100 lbs.(45.4kg), with a
combined maximum weight of 700lbs(317kg)
- Assembly requires two adults
WARNING
- Do not allow more than one child to play on the individual
swing/slide at the same time
- Do not allow children to slide down head first.
PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
For customer service, please call 1-866-370-2131 Monday-Friday 9:00am-5:00pm Eastern Time
SPORTSPOWER LTD, FLAT M, 3/FLOOR, KAISER ESTATE PHASE 3, 11 HOK YUEN STREET, HUNGHOM, KOWLOON, HK.
MODEL # MSC-3992
OWNER'S MANUAL
FOR RESIDENTIAL USE ONLY
DO NOT RETURN TO THE STORE.
or visit our website at www.sportspowerltd.net
Corporate US toll-free number 1-800-497-6106
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SPORTSPOWER MSC-3992
Summary of Contents for SPORTSPOWER MSC-3992
- Page 1 DO NOT RETURN TO THE STORE. For customer service, please call 1-866-370-2131 Monday-Friday 9:00am-5:00pm Eastern Time or visit our website at www.sportspowerltd.net SPORTSPOWER LTD, FLAT M, 3/FLOOR, KAISER ESTATE PHASE 3, 11 HOK YUEN STREET, HUNGHOM, KOWLOON, HK. Corporate US toll-free number 1-800-497-6106...
- Page 2 INTRODUCTION Dear Valued Customer, Congratulations on your Sportspower play set purchase! Please read and completely understand the contents of this owner’s manual. This manual contains specific safety instructions that must be followed to enable safe play and prevent injuries. This play set is for residential use only.
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS BEFORE YOU BEGIN: Carefully read all instructions in this manual before assembling and using this product. The unit must be assembled by adults. Heavy duty working gloves must be worn to avoid injuries during assembly. Children must not use the equipment until properly assembled and anchored. Adult supervision is required during the use of this equipment at all times WARNING READ ALL INSTRUCTIONS BEFORE ASSEMBLYING OR USING THIS EQUIPMENT... - Page 4 The following is a list of recommended ground covers from the Consumer Product Safety Commission: SUGGESTED MATERIAL SUGGESTED MATERIAL 9” Double Shredded Bark Mulch Uniform Wood Chips 12” Fine Gravel 12” Fine Sand 12” The Consumer Product Safety Commission’s Outdoor Home Playground Safety Handbook recommends to install and maintain the playground equipment over at least 9 inches of wood chips, mulch or shredded rubber (for equipment up to 8 feet high) or sand or pea gravel (for equipment no more than 5 feet high) as shock absorbing material.
- Page 5 REGULAR INSPECTION OF THE EQUIPMENT • DO NOT use the equipment if any bolts or nuts are missing or loose. ALWAYS check to ensure the equipment and all parts are well secured and stable before each use. • ALWAYS clear the play area of any rocks, sharp objects, or any materials that could be potentially hazardous to users.
- Page 6 CARE AND MAINTENANCE ANNUAL MAINTENANCE CHECKLIST AT THE BEGINNING OF EACH PLAY SEASON: • Tighten all hardware. • Lubricate all metallic moving parts per manufacturer’s instructions. • Check all protective coverings on bolts, pipes, edges and corners. Replace if they are loose, cracked or missing.
-
Page 7: Important Consumer Information Sheet
IMPORTANT CONSUMER INFORMATION SHEET The Consumer Product Safety Commission estimates there are about 200,000 playground related injuries involving children each year. Injuries involving this hazard pattern tend to be among the most serious of all playground injuries and have the potential to be fatal, particularly when the injury is to the head. The surface under and around playground equipment can be a major factor in determining the injury-causing potential of a fall. - Page 11 trapeze...
- Page 12 trapeze trapeze...
-
Page 29: Trapeze Assembly
Trapeze Assembly Step 20 Attach S to A2 Secure using S1 and S2. -
Page 33: Important Note
Important Note Please pay attention to the location of the slide system assembled in Step 22. By failing to assemble in such location in Step 23 to the swing set will create entrapment to leg, hand and head. CORRECTION LOACTION: Please attach A5 to the side of A2 and make sure the 2 holes on A5 are close to you when facing the swing set as show below. -
Page 36: Manufacturer's Limited Warranty
MANUFACTURER’S LIMITED WARRANTY SPORTSPOWER LTD. Warrants its GYM products for (180) days against defects in material, workmanship and rust painted parts which compromises the structural integrity of the product when used for the purpose intended, normal conditions, and provided it receives proper care and maintenance.
