ENDURANCE® HIGH-FLOW FILTRATION SYSTEMS
INSTALLATION, OPERATION & MAINTENANCE GUIDE
EV943730 TWIN SYSTEM
EV943730 Twin System

INTRODUCTION

The Pentair® Everpure® Endurance High-Flow Filtration systems are designed to treat up to 200,000 gallons of water per SEN cartridge
change cycle. The systems use a pretreatment Hollow Fiber Ultrafilter (HFUF), 2, 3 or 4 fine filter cartridges and a 2SR-BW scale inhibiting
cartridge.

INSPECTION

Before mounting the Pentair Everpure Endurance High-Flow system, use the table and illustration to verify the parts and quantities. If any
parts are missing, contact Customer Service at 630.307.3000 (Main) / 800.942.1153 (US only) or email at cseverpure@pentair.com.
1
3 4
PENTAIR® EVERPURE® ENDURANCE® HIGH-FLOW WATER FILTRATION SYSTEMS INSTALLATION, OPERATION & MAINTENANCE GUIDE
EV943731 TRIPLE SYSTEM
EV943731 Triple System
2
5 7
6 8
EV943732 QUAD SYSTEM
EV943732 Quad System
Parts
1. Manifold with Bracket
2. Shroud
3. Pleated Endurance HF Cartridge
4. Pretreatment Housing
5. Housing Wrench
6. 2SR-BW Cartridge
7. SEN Cartridge
8. Port Plug
Twin Triple Quad
1 1 1
1 1 1
1 1 1
1 1 1
1 1 1
1 1 1
2 3 4
2 1 0
