FLOWTECH flowpress WMDA Operation And Maintenance Manual page 18

The cumulative number of power interruptions (i.e. controller turned off/power cut).
POWER
11 This is a cumulative counter, the value of which cannot be modified. If using the
INTERRUPTED
engineer's code, the counter can be reset to zero by holding the (MUTE) button.
When enabled, if a pump has been inactive for 60 days, it will start and run for
12 PULSE
2 seconds. This is to prevent the pumps from seizing.
When enabled, if there are more than 3 individual pump runs within an 8 hour
EXCESSIVE
13 period, the unit will register an <EXCESSIVE DEMAND> alarm. Enabling this option
START
may cause false alarms on some systems.
When enabled, a service reminder will be displayed after 12 months from when the
option was enabled.
14 SERVICE
To reset the service reminder, set the value to 'NO' and exit the menu. Then, re-enter
the menu and set the value to 'YES' again.
When enabled, the <LOW PRESSURE> and <FLOOD LIMIT> alarms will be disabled,
and pump 1 will run continuously for up to 24 hours until the cold fill pressure has
been reached.
Once the cold fill pressure has been reached, this option will automatically be
15 FILL SYSTEM
deactivated, and the low pressure alarm and flood limit will be reactivated. This
function is used to fill a system that is empty or at low pressure.
Care must be taken using this option as the flood limit alarm is disabled, increasing
the risk of flooding.
This option cannot be enabled on Mini pressurisation units.
If using the customer code, the menu will end at this point. After pressing (SET) once more, the controller will
display "SAVING..." and return to normal operating mode. If using the engineer's code, additional menu items
will be displayed.
The following settings are all pre-programmed in the factory and should not need to be modified on site. If
these settings appear to have been reset, the most likely cause is a power spike. If this problem persists, a
power filter may be required.
The following settings are for experienced engineers only. Incorrect configuration of these settings can cause
the equipment not to function correctly, and may cause damage to the equipment, system or property.
# Menu Item
16 PUMPS NUMBER The number of pumps installed in the pressurisation unit. T his can be set to either
17 PUMP TYPE
18 PUMP SENSE
19 SENSOR TYPE
20 SPC
CONTROLLER
21 ADDITIVE
1 or 2.
The type of pump installed in the pressurisation unit.
There are two options, which are as follows:
0 – Centrifugal Pump
1 – Piston Pump
Disabling this option will stop the controller from monitoring the pumps and
generating <PUMP FAIL> faults.
It is not recommended to disable this option.
The type of pressure sensor installed in the unit.
There are two options which are as follows:
1 – 1-6V Output, 0-10 Bar Range
2 – 1-6V Output, 0-16 Bar Range
Not required on standard Pressurisation unit
Not required on standard Pressurisation unit
Function
18
-
YES
NO
NO
NO
Default
Value
2
0
YES
1
NO
NO
